Siemens 500-636016 AS-75-R-WP Weatherproof Horn/Strobe
- Regular price
- $252.00
- Sale price
- $252.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 500-636016
Description
The Siemens 500-636016 is an AS-75-R-WP weatherproof wall-mounted horn/strobe designed for fire alarm notification in outdoor or weather-exposed areas. It combines an audible horn with a red strobe and operates from 16–33 VDC, with a 75-series strobe rating for compatible Siemens fire alarm systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Fire Detection |
| Part Number | 500-636016 |
| Subcategory | Horn/Strobe Notification Appliances |
| Model | AS-75-R-WP |
| Product Type | Weatherproof Horn/Strobe |
| Mounting | Wall Mount |
| Housing Color | Red |
| Strobe Type | Xenon |
| Strobe Rating | 115 cd outdoor / 30 cd indoor |
| Operating Voltage | 16–33 VDC |
| Horn Modes | Continuous / Code 3 |
| Flash Rate | 1 flash per second minimum |
| Operating Temperature | 32–120°F (0–49°C) |
| Humidity | Up to 93% RH |
| Approvals | UL, ULC, FM, CSFM |
| Weight | Approximately 0.41 lb |
Information About 500-636016
The 500-636016 is the Siemens AS-75-R-WP model from the AS Series of fire alarm notification appliances. Its red weatherproof housing is designed for wall mounting, while the horn provides continuous or Code 3 audible signaling. The appliance operates across a 16–33 VDC range and supports Siemens notification circuits with compatible synchronization. Its strobe is listed at 115 cd for outdoor applications under UL 1638 and 30 cd for indoor applications under UL 1971, with additional on-axis output specified by Siemens.
Key Features:
- Weatherproof Housing: Designed for wall-mounted fire alarm notification in weather-exposed locations.
- Horn/Strobe Combination: Provides simultaneous audible and visual fire alarm signaling.
- Red Housing: Uses a red enclosure and clear lens configuration for fire alarm applications.
- Strobe Output: Provides 115 cd outdoor-rated output and 30 cd indoor-rated output under applicable standards.
- Operating Voltage: Supports 16–33 VDC input operation.
- Audible Signaling: Supports continuous and Code 3 horn patterns with selectable sound levels.
- Siemens Compatibility: Designed for use with compatible Siemens fire alarm notification circuits.
- Agency Listings: Listed or approved under applicable UL, ULC, FM, and CSFM requirements.
The 500-636016 delivers the reliability and precision required for weather-exposed fire alarm notification and emergency signaling applications.
