Siemens 500-884320 AE-30U Cerberus Pyrotronics 24VDC Alarm Extender Module
- Regular price
- $599.00
- Sale price
- $599.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 500-884320
Description
The Siemens 500-884320, model AE-30U, is a Cerberus Pyrotronics alarm extender module designed for System 3 fire alarm control equipment. It provides a supervised Class B notification appliance circuit for operating compatible polarized 24 VDC or 120 VAC bells, horns, and strobes with a maximum circuit load of 1.5 A.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Fire Alarm Systems |
| Part Number | 500-884320 |
| Subcategory | Alarm Extender Modules |
| Model | AE-30U |
| Product Type | Alarm Extender Module |
| System Series | Cerberus Pyrotronics System 3 |
| Circuit Configuration | Style Y / Class B |
| Notification Appliance Voltage | 24 VDC or 120 VAC, configuration dependent |
| Maximum Output Current | 1.5 A |
| System Input Current | 6.5 mA |
| Circuit Protection | 2 A Fuse |
| Trouble Indication | Yellow LED |
| Module Connection | 10-Pin Plug and Harness Assembly |
| Mounting Requirement | 1 System 3 Module Space |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Relative Humidity | Up to 93% ±2% at 90°F (32°C) |
| Listing | UL 864 9th Edition |
| Weight | 1 lb (0.45 kg) |
Information About 500-884320
The 500-884320 is a Siemens/Cerberus Pyrotronics AE-30U Alarm Extender Module from the System 3 output module family. It interfaces with the main control panel through a ten-pin plug and harness assembly and uses a high-going DC signal for activation. The module supervises its notification appliance circuit and incorporates a yellow trouble LED that identifies an open or shorted alarm line during normal system operation. Its circuit can support compatible 24 VDC notification appliances or 120 VAC devices when the appropriate System 3 configuration and end-of-line components are installed.
Key Features:
- Class B Output: Provides an NFPA 72 Style Y / Class B notification appliance circuit for compatible signaling devices.
- 1.5 A Circuit Capacity: Supports a maximum notification appliance circuit load of 1.5 amperes.
- Dual Voltage Capability: Supports compatible polarized 24 VDC devices or 120 VAC alarm appliances depending on system configuration.
- Supervised Circuit: Monitors notification appliance wiring for open and short circuit conditions.
- Trouble Indicator: Integrated yellow LED provides visual indication of an alarm-line wiring fault.
- Panel Integration: Connects to compatible System 3 control equipment through a ten-pin plug and harness assembly.
- Placement Supervision: Removal of the module from the system generates a system trouble condition.
- Fused Output: Incorporates circuit protection for the connected alarm notification circuit.
The 500-884320 delivers the reliability and precision required for supervised notification appliance control within compatible System 3 fire alarm installations.
