Siemens 500-896226 TRI-D Dual-Input Intelligent Fire Alarm Interface Module
- Regular price
- $1,199.00
- Sale price
- $1,199.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 500-896226
Description
Siemens 500-896226 is the part number for the TRI-D dual-input intelligent interface module used in addressable fire alarm systems. It supervises and monitors two independent sets of dry contacts, allowing devices such as waterflow and valve tamper switches to communicate with compatible Siemens fire alarm control systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | Fire Alarm Systems |
| Part Number | 500-896226 |
| Subcategory | Addressable Interface Modules |
| Model | TRI-D |
| Product Type | Dual-Input Intelligent Interface Module |
| Number of Inputs | 2 |
| Input Type | Dry Contact Monitoring |
| Addresses Required | 2 |
| Addressing Method | Electronic |
| Programming Devices | DPU or FPI-32 |
| Status Indication | Multicolor LED |
| Connection Type | Screw Terminals |
| Compatible Systems | Siemens MXL, MXLV, MXL-IQ |
| Typical Application | Waterflow and Valve Tamper Switch Monitoring |
| Weight | 7 oz (0.2 kg) |
Information About 500-896226
The 500-896226 is a Siemens TRI-series intelligent initiating interface module designed for addressable fire alarm applications. It provides two independent inputs and requires two address settings, with electronic addressing programmed through a compatible DPU or FPI-32 programmer/tester. The module incorporates a multicolor LED status indicator and screw-terminal connections for integration with an addressable circuit. It is compatible with legacy Siemens/Pyrotronics systems including MXL, MXLV, and MXL-IQ platforms and has been superseded by the XTRI-D.
Key Features:
- Dual-Input Design: Supervises and monitors two independent sets of dry contacts.
- Two Address Points: Requires two address settings, one for each monitored input.
- Electronic Addressing: Address information is electronically programmed and stored in non-volatile memory.
- Multicolor LED: Provides visual status indication through an integrated LED.
- Dry Contact Monitoring: Suitable for monitoring devices such as waterflow and valve tamper switches.
- Addressable Interface: Connects directly to compatible intelligent fire alarm addressable circuits.
- Legacy System Compatibility: Designed for applicable Siemens MXL, MXLV, and MXL-IQ fire alarm systems.
- Replacement Model: The discontinued TRI-D is superseded by Siemens XTRI-D.
The 500-896226 delivers the reliability and precision required for dual-input monitoring and addressable fire alarm system integration.
