Siemens 6GK5788-2FC00-0AB0 SCALANCE W788-2 RJ45 Industrial WLAN Access Point
- Regular price
- $2,902.00
- Sale price
- $2,902.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 6GK5788-2FC00-0AB0
Description
The Siemens 6GK5788-2FC00-0AB0 is a SCALANCE W788-2 RJ45 industrial wireless LAN access point with two radios for connecting automation equipment. It supports 2.4 and 5 GHz operation, a gross wireless rate of up to 450 Mbit/s per radio, and a Gigabit Ethernet connection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | PLCs/Machine Control |
| Part Number | 6GK5788-2FC00-0AB0 |
| Subcategory | PLC Module/Rack |
| Product Model | SCALANCE W788-2 RJ45 |
| Device Type | Industrial WLAN access point |
| Number of Radios | 2 |
| Wireless Standards | IEEE 802.11a/b/g/h/n |
| Operating Frequency Bands | 2.4 GHz and 5 GHz |
| Maximum Wireless Data Rate | 450 Mbit/s gross per radio |
| Ethernet Interface | One RJ45 port, up to 1 Gbit/s |
| Antenna Connections | Six R-SMA connectors |
| Power Supply Options | Power over Ethernet or redundant 24 V DC |
| DC Power Connection | Terminal block |
| Optional Functions | iFeatures through compatible KEY-PLUG |
| Security and Traffic Features | WPA2; IEEE 802.11i/e support |
| Protection Rating | IP30 |
| Ambient Temperature | −20 °C to +60 °C |
| Regional Version | For use in the USA only |
| Weight | 1.941 kg |
Information About 6GK5788-2FC00-0AB0
The 6GK5788-2FC00-0AB0 is part of Siemens’ SCALANCE W788 RJ45 family for control cabinet installation. Six R-SMA antenna connectors provide external antenna connections for its two wireless radios. The device supports Power over Ethernet or redundant 24 V DC power through terminal connections. This article is the USA-specific version, with optional iFeatures enabled through a compatible KEY-PLUG.
Key Features:
- Dual Wireless Radios: Provides two radios for configuring industrial wireless connections.
- Dual-Band Operation: Supports communication in the 2.4 GHz and 5 GHz frequency bands.
- Wireless Data Rate: Offers a gross transmission rate of up to 450 Mbit/s per radio.
- Gigabit Ethernet Port: Includes one RJ45 interface supporting speeds up to 1 Gbit/s.
- External Antenna Connections: Provides six R-SMA connectors for compatible antennas.
- Flexible Power Supply: Supports PoE and redundant 24 V DC terminal-connected power.
- KEY-PLUG Expansion: Supports optional iFeatures through a compatible KEY-PLUG.
- Status Signaling: Includes a signal contact for integration into equipment monitoring circuits.
The 6GK5788-2FC00-0AB0 delivers the reliability and precision required for industrial wireless connectivity between automation equipment and Ethernet networks.
