Siemens FD63F250 250A 3-Pole 600V Sentron FD Circuit Breaker Frame
- Regular price
- $697.00
- Sale price
- $697.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FD63F250
Description
The Siemens FD63F250 is a 3-pole molded-case circuit breaker frame designed for industrial and commercial electrical distribution systems. It has a 250 A current rating, a 600 VAC voltage rating, and thermal-magnetic protection with long-time and instantaneous trip functions. Its bolt-on mounting and standard interrupting capacity make it suitable for compatible FD-frame circuit protection applications.
Technical Specifications
|
Condition |
New/Never Used Surplus |
|
Brand |
Siemens |
|
Category |
Circuit Breakers |
|
Part Number |
FD63F250 |
|
Subcategory |
Molded Case Circuit Breakers |
|
Series |
Sentron FD |
|
Frame Type |
FD |
|
Rated Current |
250 A |
|
Voltage Rating |
600 VAC |
|
Number of Phases |
3 |
|
Interrupting Rating |
22 kAIC at 600 V; 35 kAIC at 480 V |
|
Trip Type |
Thermal-magnetic |
|
Trip Functions |
Long-time and instantaneous |
|
Mounting Type |
Bolt-on |
|
Terminal Connection |
Line-side and load-side lugs |
|
Wire Gauge |
Copper: AWG 6 to 350 kcmil; Aluminum: AWG 4 to 350 kcmil, as supplied |
|
Temperature Rating |
40 °C |
|
Approvals |
UL, IEC, as listed by supplier |
|
Weight |
8.00 lb |
Information About FD63F250
The FD63F250 is part of Siemens’ Sentron FD series of low-voltage molded-case circuit breaker equipment. It is rated for 22 kA interrupting capacity at 600 V and 35 kA at 480 V. The listed terminal configuration uses line-side and load-side lugs, with supported conductor sizes depending on conductor material. Confirm the installed trip unit and breaker configuration before replacing an existing unit.
Key Features:
-
Current Rating: Supports electrical systems rated up to 250 A.
-
Voltage Rating: Designed for applications up to 600 VAC.
-
Three-Pole Design: Provides switching and protection across three phases.
-
Thermal-Magnetic Protection: Uses thermal and magnetic trip mechanisms.
-
Trip Functions: Includes long-time and instantaneous trip functions.
-
Interrupting Capacity: Rated at 22 kAIC at 600 V and 35 kAIC at 480 V.
-
Bolt-On Mounting: Uses a bolt-on connection for compatible panel installations.
-
Sentron FD Series: Designed for compatible Siemens FD-frame circuit breaker applications.
The FD63F250 delivers the reliability and precision required for three-phase circuit protection in compatible industrial and commercial electrical systems.
