Siemens HEM3M030L 30A 3-Pole Motor Circuit Protector 480V Magnetic Trip ED Frame
- Regular price
- $1,345.00
- Sale price
- $1,345.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: HEM3M030L
Description
The Siemens HEM3M030L is a molded case circuit breaker designed specifically for motor circuit protection in industrial applications. With a 30 amp rating and magnetic-only trip functionality, it provides rapid response to short-circuit conditions. This breaker is engineered for reliable performance in motor control systems operating at up to 480 volts.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Part Number | HEM3M030L |
| Category | Circuit Breaker |
| Subcategory | Molded Case Circuit Breaker |
| Product Type | Motor Circuit Protector |
| Series | HEM |
| Frame Size | ED / EG Frame |
| Current Rating | 30 A |
| Voltage Rating | 480 V |
| Poles | 3 Pole |
| Phase | 3 Phase |
| Interrupting Rating | Up to 65 kA @ 480 V |
| Trip Unit | Magnetic Only |
| Functions | Instantaneous Trip |
| Connection Type | Lug / Feed-Thru |
| Frequency | 50/60 Hz |
| Certifications | UL Listed |
| Country of Origin | Dominican Republic |
| Weight | 3 lbs |
Information About HEM3M030L
The HEM3M030L is a Siemens motor circuit protector from the HEM series, built on the ED/EG frame platform for industrial motor protection systems. It features a 3-pole configuration and utilizes a magnetic-only trip unit, enabling instantaneous response to fault currents without thermal delay. Designed for integration into motor control centers and panelboards, it supports high interrupting capacity for demanding applications. With lug-type connections and UL certification, it ensures secure installation and compliance with industrial safety standards.
Key Features:
- 30 Amp Rating: Provides protection for small to medium motor loads
- Magnetic-Only Trip: Instantaneous response to short-circuit faults without thermal delay
- 3-Pole Configuration: Suitable for three-phase motor control systems
- High Interrupting Capacity: Typically rated up to 65 kA at 480V for industrial safety
- Motor Circuit Protection: Specifically designed for motor starter and control applications
- Lug-Type Connections: Ensures secure and stable wiring termination
- ED/EG Frame Design: Compatible with Siemens panelboards and motor control centers
- UL Listed Certification: Meets industry safety and compliance standards
The HEM3M030L delivers the reliability and precision required for fast-acting motor circuit protection in industrial control systems.
