Siemens LAL2.25-110V Oil Burner Control for Multistage and Modulating Burners with Air Pressure Supervision
- Regular price
- $1,555.00
- Sale price
- $1,555.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: LAL2.25-110V
Description
The Siemens LAL2.25-110V is an oil burner control that sequences startup and supervises combustion in medium- to high-capacity heating equipment. It supports multistage or modulating oil atomizing burners and incorporates air pressure supervision.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | HVAC |
| Part Number | LAL2.25-110V |
| Subcategory | Burner Control |
| Series | LAL2 |
| Burner Application | Medium- to high-capacity oil atomizing burners |
| Control Compatibility | Multistage or modulating burners |
| Power Supply | 100–110 VAC nominal; tolerance from 100 V −15% to 110 V +10% |
| Supply Frequency | 50–60 Hz ±6% |
| Power Consumption | Approximately 3.5 VA |
| Operating Duty | Intermittent; at least one controlled shutdown every 24 hours |
| Compatible Flame Detectors | QRB1, QRB3, or RAR9 |
| Prepurge Time | 22.5 seconds at 50 Hz |
| Ignition Safety Time | 5 seconds at 50 Hz |
| Short Preignition Time | 2.5 seconds at 50 Hz |
| Postignition Time | 15 seconds at 50 Hz |
| Enclosure Protection | IP40 when installed, excluding the terminal base connection area |
| Operating Temperature | −20 to +60°C |
| Weight | 2.00 lbs |
Information About LAL2.25-110V
The LAL2.25-110V is a member of the Siemens LAL2 burner control family. Its plug-in construction includes a black plastic housing and a sequence-linked lockout indicator. The 110-volt version works with QRB1/QRB3 photoresistive detectors or an RAR9 photocell detector. It is designed for intermittent operation, requiring at least one controlled shutdown every 24 hours.
Key Features:
- Burner Compatibility: Supports multistage and modulating oil atomizing equipment.
- Air Pressure Supervision: Monitors the external air pressure switch during the burner sequence.
- Flame Detection: Accepts compatible QRB1, QRB3, or RAR9 detectors.
- Timed Sequencing: Coordinates purge, ignition, and fuel valve operation.
- Fault Indication: Displays the sequence position associated with lockout.
- Plug-In Construction: Fits a compatible Siemens terminal base for equipment integration.
The LAL2.25-110V delivers the reliability and precision required for supervised oil burner startup and combustion control.
