Siemens SQM10.16502 10Nm 230VAC Damper Actuator 5 Auxiliary Switches
- Regular price
- $882.00
- Sale price
- $882.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SQM10.16502
Description
The Siemens SQM10.16502 is a reversible electromotoric actuator designed for controlling air dampers and regulating devices in burner and HVAC systems. It provides 10 Nm nominal torque, 15 Nm starting torque, and operates at 230 VAC. The actuator moves through 90° in 29 seconds or 130° in 42 seconds at 50 Hz and includes five adjustable auxiliary switches.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Siemens |
| Category | HVAC & Burner Controls |
| Part Number | SQM10.16502 |
| Subcategory | Damper Actuators |
| Series | SQM10 |
| Device Type | Reversible Electromotoric Actuator |
| Application | Air Dampers and Burner Control Valves |
| Supply Voltage | AC 220–240 V |
| Frequency | 50 Hz / 60 Hz |
| Nominal Torque | 10 Nm |
| Starting Torque | 15 Nm |
| Holding Torque | 7 Nm |
| Running Time at 90° | 29 s at 50 Hz |
| Running Time at 130° | 42 s at 50 Hz |
| Maximum Angular Rotation | 160° |
| Direction of Rotation | Counterclockwise |
| Auxiliary Switches | 5 |
| Drive Shaft Diameter | 10 mm |
| Power Consumption | 9 VA |
| Protection Rating | IP54 |
| Operating Temperature | -20°C to +60°C |
| Mounting Position | Optional |
| Weight | 1.771 kg |
Information About SQM10.16502
The SQM10.16502 is a Siemens SQM10 Series actuator with a 10 mm drive shaft and counterclockwise rotation. It is designed for use with controllers or switching devices equipped with changeover contacts and can operate air dampers and control valves associated with forced-draft burners. The unit operates from AC 220–240 V at 50 Hz or AC 220 V at 60 Hz and consumes approximately 9 VA. It provides IP54 protection and has an operating temperature range of -20°C to +60°C.
Key Features:
- 10 Nm Nominal Torque: Provides 10 Nm of torque for positioning dampers and regulating devices.
- 15 Nm Starting Torque: Provides increased starting torque for reliable actuator movement.
- 90°/29 s Operation: Reaches a 90° angular position in approximately 29 seconds at 50 Hz.
- 130°/42 s Operation: Provides a 130° movement time of approximately 42 seconds at 50 Hz.
- Five Auxiliary Switches: Includes five manually adjustable auxiliary switches for position control and signaling.
- Counterclockwise Rotation: Provides counterclockwise shaft rotation when viewed from the drive shaft.
- 230 VAC Operation: Designed for AC 220–240 V operation at 50 Hz or AC 220 V at 60 Hz.
- IP54 Protection: Provides protection suitable for enclosed industrial burner and HVAC installations.
The SQM10.16502 delivers the reliability and precision required for air-damper positioning, burner control, and industrial HVAC applications.
