Simplex 4090-9119 IDNet Relay IAM with Unsupervised Input Module
- Regular price
- $57.00
- Sale price
- $57.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 4090-9119
Description
The Simplex 4090-9119 is an addressable Relay Individual Addressable Module (IAM) that combines relay control and input monitoring in a single compact device. Designed for use with compatible Simplex fire alarm control panels, it enables efficient monitoring of unsupervised dry contacts while providing Form C relay output using only one IDNet address. Its integrated design simplifies installation for fire protection and building control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Simplex |
| Category | Fire Alarm Systems |
| Part Number | 4090-9119 |
| Subcategory | Addressable Relay Modules |
| Device Type | Relay Individual Addressable Module (IAM) with unsupervised input |
| Communication Protocol | IDNet |
| Address Requirement | One IDNet address |
| Point Configuration | Dual point (1 relay output, 1 unsupervised input) |
| Input Type | Normally open dry contact, unsupervised |
| Maximum Input Wiring Distance | 500 ft (152 m) |
| Relay Type | Form C (SPDT), latching |
| Relay Rating (DC) | 2 A @ 30 VDC resistive; 1 A @ 30 VDC inductive |
| Relay Rating (AC) | 0.5 A @ 120 VAC resistive; 0.25 A @ 120 VAC inductive |
| Power Source | Powered directly from IDNet communications loop |
| Wire Size | 18–14 AWG (0.82–2.08 mm²) |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Humidity Range | 10% to 90% RH |
| Dimensions | 4.13 × 4.13 × 1.38 in. (105 × 105 × 35 mm) |
| Mounting | Standard 4 in. square electrical box |
| Housing Material | Black thermoplastic housing on metal mounting plate |
| Listings | UL, ULC, CSFM, FM Approved, MEA (NYC) |
| Weight | Approx. 0.5 lb (0.23 kg) |
Information About 4090-9119
The 4090-9119 is a dual-point addressable module from the Simplex IDNet peripheral family that combines one relay output and one unsupervised input within a single enclosure. It communicates directly with compatible Simplex fire alarm control panels over the IDNet signaling line circuit while drawing operating power from the communications loop, eliminating the need for a separate power supply. The module is commonly used for fan control, smoke management, equipment monitoring, and other building automation functions that require both output control and status feedback. Its sealed construction, onboard LED indicator, and standard electrical box mounting provide dependable operation in commercial indoor installations.
Key Features:
- Dual-Point Module: Combines one relay output and one unsupervised input using a single IDNet address.
- Form C Relay Output: Provides SPDT relay contacts for control of external equipment.
- Unsupervised Input Monitoring: Monitors normally open dry contact inputs for equipment status feedback.
- IDNet Powered: Receives both communication and operating power directly from the IDNet loop.
- LED Communication Indicator: Visible LED flashes to indicate normal communication status.
- Compact Sealed Housing: Reduces dust infiltration and protects internal electronics.
- Flexible Applications: Suitable for fan control, smoke control, and general building system monitoring.
- Standard Electrical Box Mounting: Fits a 4-inch square electrical box with optional trim plates available.
The 4090-9119 delivers the reliability and precision required for addressable relay control and equipment status monitoring in commercial fire alarm systems.
