Simplex 565-256 Power Supply Interface Board for 4020 Fire Alarm Control Panels
- Regular price
- $2,099.00
- Sale price
- $2,099.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 565-256
Description
The Simplex 565-256 is a power supply interface board designed for the Simplex 4020 fire alarm control panel platform. It interfaces with the system power supply to supervise operating voltages and current, provide internal voltage conversion, monitor power-supply trouble conditions, and support ground-fault detection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Simplex |
| Category | Fire Alarm Systems |
| Part Number | 565-256 |
| Subcategory | Power Supply Interface Board |
| Product Type | Power Input/Output Interface Assembly |
| Compatible System | Simplex 4020 Fire Alarm Control Panel |
| Compatible Power Supply | Simplex 636-341 Universal Switcher Power Supply |
| Compatible Standard Slave Board | Simplex 565-368 |
| Primary Direct-Current Interface | 28.5 volts direct current |
| Internal Voltage Conversion | +5 volts and +36 volts |
| Monitoring Method | Analog-to-Digital Voltage and Current Supervision |
| Power Supply Supervision | Supported |
| Ground-Fault Detection | Supported |
| Power Tap Control | Jumper Configurable |
| Production Status | Discontinued |
| Weight | 2.20 lbs |
Information About 565-256
The 565-256 is a Simplex Power Input/Output Interface assembly developed specifically for later configurations of the 4020 fire alarm system. Its electronic circuitry interfaces with the 636-341 Universal Switcher Power Supply and converts the incoming 28.5-volt direct-current supply into the regulated voltages required by internal system electronics. The board is designed for use with the 565-368 Standard Slave printed circuit board and the associated system software configuration. In addition to power conversion, it performs power-supply supervision, voltage and current monitoring through an analog-to-digital converter, trouble monitoring, tap voltage control, and ground-fault detection.
Key Features:
- 4020 System Compatibility: Designed as a power supply interface assembly for the Simplex 4020 fire alarm control panel platform.
- Power Supply Interface: Interfaces with the 636-341 Universal Switcher Power Supply used in the corresponding 4020 system configuration.
- Voltage Conversion: Converts approximately 28.5 volts direct current into +5-volt and +36-volt supplies required for internal system functions.
- Power Supervision: Provides the interface used by the control system for supervision and control of power-supply operation.
- Voltage and Current Monitoring: Incorporates analog-to-digital conversion for supervision of power-supply voltage and current conditions.
- Ground-Fault Detection: Performs ground-fault monitoring as part of the 4020 power-management architecture.
- Configurable Power Taps: Uses jumper selections to enable the main system supply and designated power taps required by the panel configuration.
- Standard Slave Compatibility: Specifically pairs with the Simplex 565-368 Standard Slave printed circuit board rather than the earlier 565-222 configuration.
The 565-256 delivers the reliability and precision required for power conversion, supply supervision, fault monitoring, and internal power distribution in compatible Simplex 4020 fire alarm systems.
