Product Description P/N: SKLA36AT1200
Description
The General Electric SKLA36AT1200 is a high-capacity molded case circuit breaker designed for reliable protection of electrical systems in industrial and commercial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | General Electric |
| Category | Circuit Breaker |
| Part Number | SKLA36AT1200 |
| Subcategory | Molded Case Circuit Breaker |
| Series | Spectra Series |
| Amperage Rating | 1200 A |
| Voltage Rating | 600 VAC |
| Voltage Type | AC |
| Poles | 3 |
| Phase | 3 Phase |
| Frame Type | SKLA |
| Interrupting Capacity | 65 kAIC @ 480 V |
| Trip Functions | Long Time, Short Time, Instantaneous |
| Trip Unit Type | Solid State, Interchangeable RMS Trip |
| Termination | Bolt-On |
| Special Features | High Interrupting Capacity, Suitable for Reverse Fed Applications |
| Weight | 32.00 lbs |
Information About SKLA36AT1200
The General Electric SKLA36AT1200 is a heavy-duty molded case circuit breaker from the Spectra Series, engineered for high-capacity electrical protection in industrial and commercial applications. Rated at 1200 A with a voltage capacity of 600 VAC, it features a solid-state trip unit with long time, short time, and instantaneous trip functions for precise overcurrent and short-circuit protection. With a 65 kAIC interrupting capacity at 480 V, it ensures safe and reliable performance in demanding power distribution systems. Its bolt-on termination design, interchangeable RMS trip unit, and suitability for reverse-fed applications provide flexibility for a wide range of installations.
Key Features:
- High Current Capacity: Rated for 1200 A at 600 VAC, suitable for large-scale electrical systems.
- Robust Protection: 65 kAIC interrupting capacity at 480 V for enhanced fault handling.
- Advanced Trip Functions: Solid-state trip unit with long time, short time, and instantaneous settings.
- Interchangeable RMS Trip: Allows for easy replacement or adjustment to meet system requirements.
- Flexible Installation: Bolt-on termination for secure mounting and compatibility with Spectra Series panels.
- Reverse Feed Capability: Approved for reverse-fed applications to increase wiring flexibility.
- Durable Design: Built for demanding industrial and commercial environments.
The SKLA36AT1200 delivers high-performance circuit protection with advanced features and adaptability, making it an excellent choice for critical power distribution needs.
