Sprecher + Schuh KT4-C2A-C16 3-Pole Manual Motor Protector 10–16A Class 10
- Regular price
- $827.00
- Sale price
- $827.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: KT4-C2A-C16
Description
The Sprecher + Schuh KT4-C2A-C16 is a three-pole manual motor protector designed for compact motor switching, overload protection, and short-circuit protection in industrial control panels. Adjustable from 10 to 16 A, the Sprecher + Schuh KT4-C2A-C16 provides Class 10 motor protection with phase loss and overload protection for motors operating on systems up to 600 VAC.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Sprecher + Schuh |
| Category | Motor Control |
| Part Number | KT4-C2A-C16 |
| Subcategory | Manual Motor Protectors |
| Series | KT4 |
| Product Type | Manual Motor Protector / Manual Motor Starter |
| Number of Poles | 3 |
| Current Adjustment Range | 10–16 A |
| Trip Class | Class 10 |
| Protection Functions | Thermal Overload, Phase Loss, Short Circuit |
| Magnetic Trip Type | High-Speed Magnetic Trip |
| Maximum Operating Voltage | Up to 600 VAC |
| Operator Type | Pushbutton ON/OFF |
| Mounting | DIN Rail |
| Accessory Compatibility | Auxiliary Contacts, Shunt Trip, Undervoltage Release, Bus Bar System |
| Application | Motor Protection, Group Motor Installations, Industrial Control Panels |
| Maximum Branch Circuit Protection Rating | 250 A |
| Magnetic Response Current | 176 A |
| Weight | Approximately 1.0 lb |
Information About KT4-C2A-C16
The KT4-C2A-C16 is part of the Sprecher + Schuh KT4 Series of manual motor starters developed for branch motor protection and compact motor control applications. It combines manual ON/OFF switching, thermal overload protection, and high-speed magnetic short-circuit tripping in a single DIN rail-mounted device. The protector uses a pushbutton operator and can be expanded with auxiliary contacts, shunt trip modules, undervoltage release modules, bus bars, and enclosure options. Its compact design helps reduce panel space and installation cost in group motor applications while maintaining reliable motor protection performance.
Key Features:
- Manual Motor Protector: Combines motor switching and protection in one compact unit.
- Adjustable Current Range: Adjustable from 10 to 16 A for motor overload protection.
- Three-Pole Design: Suitable for three-phase motor control applications.
- Class 10 Trip Characteristic: Provides fast overload response for motor protection.
- Phase Loss Protection: Helps protect motors from damage caused by phase failure.
- High-Speed Magnetic Trip: Limits let-through current during short-circuit conditions.
- Pushbutton ON/OFF Control: Provides simple manual motor starting and stopping.
- DIN Rail Mounting: Allows fast installation in industrial control panels.
- Compact Footprint: Helps reduce panel space compared with separate protection components.
- Accessory Compatible: Supports auxiliary contacts, shunt trip, undervoltage release, and bus bar systems.
- Group Motor Application Support: Suitable for group motor installations with proper system coordination.
The KT4-C2A-C16 delivers the reliability and precision required for compact industrial motor protection and control applications.
