Square D ARP060 Rating Plug 100-4000A 600VAC for LX MX NX PX SE Series Circuit Breakers
- Regular price
- $1,329.00
- Sale price
- $1,329.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: ARP060
Description
The Square D ARP060 is a rating plug designed for use in compatible Square D circuit breakers, supporting adjustable amperage settings within a defined protection range. It enables precise calibration of the breaker’s trip current to match system requirements. This component is essential for tailoring protection characteristics in low-voltage power distribution systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Protection |
| Part Number | ARP060 |
| Subcategory | Rating Plugs |
| Series | ARP |
| Amperage Range | 100–4000 A |
| Voltage Rating | 600 VAC |
| Compatible Frames | LX, LXP, LXL, LXF, LE, LEP, LEL, LEF, MX, MXP, MXL, MXF, ME, MEP, MEL, MEF, NX, NXL, NXP, NXF, NE, NEL, NEP, NEF, PX, PXF, PXL, PXP, PE, PEL, PEP, PEF, SED, SEHD, SEF, SEHF |
| Function Type | Rating Plug |
| Installation Type | Plug-In |
| Application | Power Distribution Systems |
| Weight | 0.3 lb |
Information About ARP060
The ARP060 is part of Square D’s ARP series of rating plugs, engineered to work with a wide range of molded case and power circuit breaker frames. It is designed to define the continuous current rating and influence the trip characteristics of the breaker by setting the maximum allowable current. Built for compatibility with multiple frame types including LX, MX, NX, PX, and SE series, it offers flexibility across various installations. This rating plug operates in systems up to 600VAC and is commonly used in industrial and commercial distribution panels where accurate overcurrent protection is required.
Key Features:
- Adjustable Current Range: Supports a broad amperage range from 100A to 4000A depending on breaker configuration
- Protection Calibration: Defines breaker trip thresholds for precise overcurrent protection
- Wide Compatibility: Designed for use with LX, MX, NX, PX, SE, and related frame types
- Voltage Rating: Suitable for systems up to 600VAC
- Plug-In Design: Allows quick installation and replacement without complex modifications
- Series Integration: Part of the Square D ARP series for standardized breaker accessories
- Durable Construction: Engineered for long-term reliability in demanding electrical environments
- Application Flexibility: Suitable for industrial, commercial, and utility power distribution systems
The ARP060 delivers the reliability and precision required for accurate current protection in low-voltage circuit breaker systems.
