Square D BDA36125 PowerPact B 125 Ampere Three-Pole I-Line Molded Case Circuit Breaker
- Regular price
- $797.00
- Sale price
- $797.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: BDA36125
Description
The Square D BDA36125 is a Schneider Electric PowerPact B molded case circuit breaker designed for overload and short-circuit protection in commercial and industrial power distribution systems. It provides a 125-ampere rating, three-pole configuration, 600Y/347-volt alternating-current capability, and thermal-magnetic protection with I-Line mounting.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | BDA36125 |
| Subcategory | Molded Case Circuit Breaker |
| Manufacturer | Schneider Electric |
| Product Family | PowerPact B |
| Frame Type | B Frame |
| Current Rating | 125 amperes |
| Number of Poles | 3 |
| Voltage Rating | 600Y/347 volts alternating current |
| Frequency Rating | 50/60 hertz |
| Interrupting Rating | 25,000 amperes at 240 volts; 18,000 amperes at 480 volts; 14,000 amperes at 600Y/347 volts alternating current |
| Protection Type | Thermal-Magnetic |
| Trip Functions | Long-Time and Instantaneous |
| Continuous Current Rating | 80 percent |
| Mounting Type | I-Line Plug-In |
| Terminal Connection | I-Line Connection on Line Side; Mechanical Lug on Load Side |
| Conductor Range | 14 through 2/0 American Wire Gauge, Aluminum or Copper |
| Phase Connection | ABC |
| Weight | 4.21 lbs |
Information About BDA36125
The BDA36125 is a Square D PowerPact B Series molded case circuit breaker manufactured by Schneider Electric with a compact B-frame construction and factory-sealed trip unit. Its thermal-magnetic mechanism provides fixed long-time overload and instantaneous short-circuit protection, while dual-break rotating contacts help limit peak current during fault conditions. The breaker uses an isolated I-Line plug-on connection on the line side and mechanical lugs on the load side for aluminum or copper conductors from 14 through 2/0 American Wire Gauge. It is intended for compatible I-Line panelboards and electrical distribution equipment and carries an 80-percent continuous current rating with an ABC phase connection.
Key Features:
- 125-Ampere Rating: Provides a rated current of 125 amperes at 40 degrees Celsius for commercial and industrial distribution circuits.
- Three-Pole Configuration: Uses three poles with an ABC phase arrangement for compatible three-phase electrical systems.
- 600Y/347-Volt Capability: Rated for 600Y/347-volt alternating-current distribution applications at 50 or 60 hertz.
- Thermal-Magnetic Protection: Uses a factory-sealed thermal-magnetic trip unit for overload and short-circuit protection.
- Long-Time and Instantaneous Functions: Provides long-time response to sustained overload conditions and instantaneous operation during high-current faults.
- Multiple Interrupting Ratings: Provides 25,000 amperes at 240 volts, 18,000 amperes at 480 volts, and 14,000 amperes at 600Y/347 volts alternating current.
- I-Line Installation: Uses a shrouded I-Line plug-on jaw on the line side with mechanical load-side lugs for compatible Square D distribution equipment.
- Standards Compliance: Certified to applicable UL, CSA, NOM, International Electrotechnical Commission, and CCC requirements and carries CE marking.
The BDA36125 delivers the reliability and precision required for overload and short-circuit protection in commercial and industrial I-Line power distribution systems.
