Square D HDA36025 PowerPact H 25 Ampere Three-Pole 600 Volt Molded Case Circuit Breaker
- Regular price
- $825.00
- Sale price
- $825.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: HDA36025
Description
The Square D HDA36025 is a Schneider Electric PowerPact H molded case circuit breaker designed to protect commercial and industrial power distribution circuits against overloads and short circuits. It provides a 25-ampere rating, three-pole construction, operation up to 600 volts alternating current, and fixed thermal-magnetic protection with I-Line mounting.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | HDA36025 |
| Subcategory | Molded Case Circuit Breaker |
| Manufacturer | Schneider Electric |
| Product Family | PowerPact H |
| Frame Type | H Frame, 150-Ampere Frame |
| Current Rating | 25 amperes |
| Number of Poles | 3 |
| Voltage Rating | 600 volts alternating current / 250 volts direct current |
| Frequency Rating | 50/60 hertz |
| Interrupting Rating | 25,000 amperes at 240 volts; 18,000 amperes at 480 volts; 14,000 amperes at 600 volts alternating current; 20,000 amperes at 250 volts direct current |
| Protection Type | Thermal-Magnetic |
| Trip Functions | Long-Time and Instantaneous |
| Continuous Current Rating | 80 percent |
| Mounting Type | I-Line Plug-In |
| Terminal Connection | I-Line Connection on Line Side; Mechanical Lugs on Load Side |
| Conductor Range | 14 through 3/0 American Wire Gauge, Aluminum or Copper |
| Phase Connection | ABC |
| Weight | 4.90 lbs |
Information About HDA36025
The HDA36025 is a Square D PowerPact H Series molded case circuit breaker built on the 150-ampere H frame for three-phase electrical distribution applications. Its fixed thermal-magnetic trip unit combines long-time overload protection with instantaneous short-circuit protection and operates through a manual toggle mechanism. The breaker uses an isolated I-Line plug-on connection on the line side and mechanical lugs on the load side, accepting aluminum or copper conductors from 14 through 3/0 American Wire Gauge. It is compatible with Square D I-Line distribution equipment and has an 80-percent continuous current rating with an ABC phase connection.
Key Features:
- 25-Ampere Current Rating: Provides a fixed 25-ampere rating for branch, feeder, and equipment circuit protection.
- Three-Pole Construction: Uses three poles with an ABC phase connection for compatible three-phase power distribution systems.
- Dual Voltage Capability: Rated for up to 600 volts alternating current and 250 volts direct current.
- Thermal-Magnetic Protection: Uses a fixed thermal element for sustained overload conditions and a magnetic element for high-current short circuits.
- Long-Time and Instantaneous Functions: Provides long-time overload protection and instantaneous short-circuit tripping without an electronic trip unit.
- Multiple Interrupting Ratings: Provides 25,000 amperes at 240 volts, 18,000 amperes at 480 volts, and 14,000 amperes at 600 volts alternating current.
- I-Line Mounting: Uses an I-Line line-side connection with mechanical load-side lugs for installation in compatible Square D distribution equipment.
- Standards Compliance: PowerPact H breakers are UL 489 listed and certified or compliant with applicable CSA, NEMA, NOM, International Electrotechnical Commission, and CE requirements.
The HDA36025 delivers the reliability and precision required for overload and short-circuit protection in commercial and industrial I-Line power distribution systems.
