HDL26100 | Square D PowerPact H 100A 2-Pole Molded Case Circuit Breaker, 600V
- Regular price
- $599.00
- Sale price
- $599.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: HDL26100
Description
The Square D HDL26100 is a molded case circuit breaker designed to provide dependable overcurrent protection in commercial and industrial electrical distribution systems. This 2-pole breaker is rated at 100 amps and supports both AC and DC applications using thermal magnetic, current-limiting trip technology. Built on a robust H-frame platform, the HDL26100 delivers consistent performance across a wide range of distribution environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Breaker |
| Part Number | HDL26100 |
| Subcategory | Molded Case Circuit Breaker |
| Series | PowerPact H |
| Frame Size | H Frame |
| Breaker Type | HDL |
| Amperage Rating | 100 A |
| Voltage Rating | 600 VAC / 250 VDC |
| Number of Poles | 2 |
| Phase | Single Phase |
| Frequency Rating | 50/60 Hz |
| Trip Unit Type | Thermal Magnetic, Current Limiting |
| Trip Functions | Long-Time and Instantaneous |
| Interrupt Rating | 25 kA @ 240 VAC; 18 kA @ 480 VAC; 14 kA @ 600 VAC |
| Mounting Type | Unit Mount |
| Connection Type | Feed-Thru |
| Wire Size Range | AWG 14 to AWG 3/0 (Copper/Aluminum) |
| Operating Temperature | -2°C to 70°C |
| Certifications | UL 489 Listed, CSA, IEC, CE |
| Dimensions (W × D × H) | 4.09 in × 3.39 in × 6.42 in |
| Weight | 1.38 lb |
Information About HDL26100
The HDL26100 is a Square D PowerPact H-frame molded case circuit breaker engineered for high-capacity power distribution applications. It incorporates a thermal magnetic trip unit with long-time and instantaneous protection to safeguard circuits from overloads and short-circuit faults. Designed for unit-mount installation with feed-thru connections, this breaker supports flexible integration into industrial panelboards and switchgear. Its UL 489 listing and international certifications make it suitable for regulated electrical systems operating at standard power frequencies.
Key Features:
- 100 Amp Current Rating: Supports medium to high-load distribution circuits
- 2-Pole Configuration: Provides coordinated protection across two conductors
- Thermal Magnetic Trip Unit: Delivers reliable long-time and instantaneous fault response
- Current-Limiting Design: Reduces peak fault energy during short-circuit events
- H-Frame Construction: Ensures mechanical strength and durability in demanding environments
- Feed-Thru Connections: Allows efficient wiring and streamlined installation
- Wide Interrupt Capacity: Rated up to 25kA at 240VAC and 14kA at 600VAC
The HDL26100 delivers the reliability and precision required for industrial and commercial power distribution protection.
