Product Description P/N: QGL22200LU
Description
The Square D QGL22200LU is a 2-pole molded case circuit breaker designed for dependable overcurrent protection in 240VAC distribution systems. With a 200A rating and a high interrupting capacity of 65kA, it supports applications requiring strong fault-clearing capability. This breaker includes line and load lugs for straightforward installation in unit-mount configurations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Distribution Equipment |
| Part Number | QGL22200LU |
| Subcategory | Molded Case |
| Series | PowerPact Q |
| Rated Current | 200A |
| Poles | 2 |
| Operational Voltage | 240VAC 50/60 Hz |
| Interrupting Rating | 65kA @ 120/208VAC & 240VAC |
| Trip Technology | Thermal-Magnetic |
| Magnetic Trip Range | 1200A (hold), 2400A (trip) |
| Continuous Current Rating | 80% |
| Mounting Mode | Unit-mount with lugs |
| Connections | Line and load lugs |
| Control Wire Terminal | Included (line side) |
| Torque Specification | 247.8 lbf-in (28 N·m) |
| Wire Range | AWG 4 to 300 kcmil (Cu/Al) |
| Impulse Withstand Voltage | 8 kV |
| Certifications | UL, CSA, NEMA, NOM |
| Dimensions | 3 in W × 3.93 in D × 6.47 in H |
| Country of Origin | Mexico |
| Weight | 3.38 lb |
Information About QGL22200LU
The QGL22200LU is part of Square D’s PowerPact Q-Frame series, built with a rugged molded case structure engineered for commercial and industrial distribution panels. It features a thermal-magnetic trip unit that combines long-time protection with precise magnetic trip response for short-circuit conditions. Designed for 2-pole unit-mount installations, it includes a control wire terminal and operates reliably across demanding electrical environments. This model meets UL, CSA, NEMA, and NOM certifications, ensuring compatibility with North American and international safety standards.
Key Features:
- 200A Current Rating: Supports medium to high-capacity electrical loads in commercial installations.
- Thermal-Magnetic Trip Technology: Delivers overload and short-circuit protection through combined long-time and instantaneous trip functions.
- 65kA Interrupting Capacity: Provides high fault-current handling at both 120/208VAC and 240VAC.
- Unit-Mount Design: Simplifies panel installation with preconfigured line and load lug connections.
- Control Wire Terminal: Allows integration of auxiliary wiring on the line side for system control needs.
- Durable Mechanical Performance: Rated for up to 5,000 no-load cycles and 1,000 loaded cycles.
- HACR Rated: Suitable for heating, air-conditioning, and refrigeration equipment.
- Wide Environmental Tolerance: Operates within demanding ambient temperatures up to 70°C (158°F).
The QGL22200LU delivers the reliability and precision required for molded case circuit protection in commercial and industrial power distribution systems.
