SR-G100 | Keyence Handheld DPM Barcode Reader with Bluetooth, 2D/1D Code Support, IP54
- Regular price
- $929.00
- Sale price
- $929.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SR-G100
Description
The Keyence SR-G100 is a handheld DPM (Direct Part Mark) code reader engineered for high-speed scanning and stable decoding of barcodes and 2D codes, even on difficult surfaces such as metal, plastic, or cast parts. With wireless Bluetooth communication and a compact ergonomic design, it provides mobility and ease of use in industrial and logistics applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Keyence |
| Category | Bar Code Equipment |
| Part Number | SR-G100 |
| Subcategory | Bar Code Scanner Cable |
| Series | SR-G Series |
| Sensor Type | CMOS image sensor |
| Resolution | 900 × 900 pixels (2D code), 1280 × 900 pixels (barcode) |
| Light Source | High-intensity red and blue LEDs |
| Supported Codes (2D) | QR, MicroQR, DataMatrix (ECC200), PDF417, GS1 Composite |
| Supported Codes (1D) | CODE39, ITF, Code128, GS1-128, GS1 DataBar, JAN/EAN/UPC, Pharmacode |
| Minimum Resolution | 2D: 0.127 mm (0.005"); 1D: 0.10 mm (0.004") |
| Focal Distance | 30 mm (1.18") |
| Communication | Bluetooth 2.1 + EDR Class 2, USB 2.0 Full Speed |
| Communication Range | 10 m (32 ft) line-of-sight |
| Power Supply | 208–230 VAC (charging base) |
| Power Consumption | Approx. 8.5 W |
| Enclosure Rating | IP54 |
| Operating Temperature | 0 °C to +45 °C (32 °F to 113 °F) |
| Storage Temperature | –10 °C to +50 °C (14 °F to 122 °F) |
| Relative Humidity | 35–95 % RH (non-condensing) |
| Ambient Light Resistance | Sunlight: 10,000 lux; Incandescent: 6,000 lux; Fluorescent: 2,000 lux |
| Drop Resistance | 2.0 m (6.56 ft), 50 times |
| Continuous Usage Time | Approx. 10 hours (fully charged battery) |
| Charging Time | Approx. 4.5 hours |
| Dimensions | 214 × 78.5 × 97.4 mm (8.43″ × 3.09″ × 3.83″) |
| Weight | Approx. 735 g (1.62 lbs, incl. battery) |
Information About SR-G100
The SR-G100 is part of Keyence’s SR-G Series of handheld code readers, optimized for demanding traceability and identification tasks. Equipped with a high-resolution CMOS image sensor (900 × 900 pixels for 2D codes, 1280 × 900 pixels for barcodes), it delivers reliable performance for challenging DPM and label codes. The reader features multi-lighting control, automatically selecting the best illumination type—color, polarized, or multi-angle—to minimize glare and enhance code visibility. Wireless communication via Bluetooth 2.1 + EDR allows up to 10 m of cable-free operation, and USB 2.0 connectivity supports wired setup or data transfer. The SR-G100 is IP54 rated, lightweight, and features a balanced, ergonomic design that ensures operator comfort and long-term durability.
Key Features:
- High-Resolution CMOS Sensor: Provides sharp image capture for 2D and 1D barcodes, even on reflective or rough surfaces.
- Multi-Lighting System: Automatically selects optimal lighting type to eliminate reflections and enhance DPM readability.
- Wireless Operation: Bluetooth Ver. 2.1 + EDR (Class 2) enables wireless communication up to 10 m (32 ft).
- Fast and Reliable Decoding: Reads both printed and directly marked codes such as dot peen and laser-etched marks.
- Wide Code Support: Compatible with QR, DataMatrix, PDF417, GS1, Code128, and many more industrial standards.
- Automatic Calibration: Simplifies setup—adjusts focus, lighting, and contrast at the press of a button.
- Ergonomic Design: Lightweight (735 g) and balanced for comfortable extended use.
- Durable Build: IP54-rated for protection against dust and light water exposure.
- Flexible Power Options: Operates on rechargeable battery or AC power for continuous usage.
- Long Battery Life: Provides up to 10 hours of continuous use per charge.
The SR-G100 offers high-speed, stable, and user-friendly code reading for manufacturing traceability and quality control systems.
