SGMP-15AWYR11 | Yaskawa SGMP Sigma AC Servo Motor 1.5kW 200VAC 3000RPM
- Regular price
- $399.00
- Sale price
- $399.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: SGMP-15AWYR11
Description
The Yaskawa SGMP-15AWYR11 servo motor is a high-performance synchronous AC servo motor from the SGMP Sigma series, designed for precise speed and torque control in industrial automation systems. Operating at 200 VAC, it delivers 1.5 kW of rated output with a rated speed of 3000 RPM and 4.77 Nm of continuous torque. This motor is suitable for applications requiring accurate positioning, fast response, and stable operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Yaskawa |
| Category | Industrial Automation |
| Part Number | SGMP-15AWYR11 |
| Subcategory | Servo Motors |
| Product Line | SGMP Sigma Series |
| Motor Type | Synchronous AC Servo Motor |
| Rated Output | 1.5 kW |
| Rated Voltage | 200 VAC |
| Rated Current | 7.5 A |
| Rated Speed | 3000 RPM |
| Maximum Speed | 4500 RPM |
| Rated Torque | 4.77 Nm |
| Encoder Type | 12-Bit Absolute Encoder |
| Drive Method | Direct Drive |
| Cooling Method | Self-Cooling |
| Mounting Method | Flange Mount |
| Ambient Temperature | 0 to 40°C (Non-Condensing) |
| Storage Temperature | -20 to 80°C (Non-Condensing) |
| Weight | 10.00 lbs (4.54 kg) |
Information About SGMP-15AWYR11
The SGMP-15AWYR11 is part of Yaskawa’s SGMP Sigma series, a lineup of servo motors engineered for reliable motion control in demanding industrial environments. It features a direct-drive synchronous motor design combined with a 12-bit absolute encoder to ensure accurate position feedback without the need for re-homing after power loss. The motor is designed for flange mounting, allowing secure mechanical integration into machinery and automation equipment. With self-cooling construction and defined operating temperature ranges, it supports continuous operation in controlled industrial settings.
Key Features:
- SGMP Sigma Series Motor: Designed for precise and dependable industrial motion control.
- 1.5 kW Rated Output: Provides sufficient power for medium-capacity servo applications.
- High-Speed Capability: Rated at 3000 RPM with maximum speeds up to 4500 RPM.
- Continuous Torque Performance: Delivers 4.77 Nm of rated torque for stable motion.
- Absolute Encoder Feedback: Integrated 12-bit absolute encoder supports accurate positioning.
- 200 VAC Operation: Compatible with standard industrial servo drive systems.
- Flange Mount Design: Enables secure and standardized mechanical installation.
The SGMP-15AWYR11 delivers the reliability and precision required for medium-power servo motion in industrial automation and positioning systems.
