SRT2-ROC16 | Omron 16-Point Remote Relay Output Block 24 VDC
- Regular price
- $1,322.00
- Sale price
- $1,322.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: SRT2-ROC16
Description
The Omron SRT2-ROC16 is a compact remote relay output block with 16 channels, designed for high-speed communication over long distances. Operating at 24 VDC, it supports up to 3 A per contact with reliable screw terminal connections and DIN rail mounting.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | I/O Modules |
| Part Number | SRT2-ROC16 |
| Subcategory | Remote Output Modules |
| Series | SRT2 |
| Device Type | Remote Output Relay Module |
| Number of Output Channels | 16 |
| Relay Type | G6D-1A (1 per channel) |
| Rated Voltage | 24 VDC |
| Input/Output Voltage Rating | 24 VDC |
| Rated Switching Capacity (DC) | 3 A at 30 VDC (resistive) |
| Rated Switching Capacity (AC) | 3 A at 250 VAC (resistive) |
| Max Switching Power (DC) | 90 W |
| Max Switching Power (AC) | 730 VA |
| Max Current per Contact | 3 A |
| Max Voltage per Contact | 250 VAC, 30 VDC |
| Min Load Supported | 10 mA at 5 VDC |
| Electrical Lifetime | ≥100,000 cycles (1,800 cycles/h) |
| Mechanical Lifetime | 20 million cycles (18,000 cycles/h) |
| Communication Speed | 750 kbps |
| Communication Distance | Up to 500 m |
| Termination Style | Screw terminals |
| Mounting Type | DIN Rail |
| Weight | 0.53 lb (240 g) |
Information About SRT2-ROC16
The SRT2-ROC16 is a high-density remote output relay module in the Omron SRT2 series, designed to provide distributed control in space-constrained industrial environments. It supports 16 relay output channels, each using a G6D-1A relay for dependable switching performance. The unit communicates over long distances (up to 500 m) with a high-speed 750 kbps protocol, ensuring minimal latency in control response. Rated for 24 VDC operation, this module is DIN-rail mountable and supports robust AC/DC switching capacities for both resistive and inductive loads.
Key Features:
-
16 Relay Output Channels: Supports discrete control of devices with one relay (G6D-1A) per channel for enhanced reliability.
-
3 A Contact Capacity: Handles up to 3 A per channel at 30 VDC or 250 VAC for both resistive and inductive loads.
-
High-Speed Communication: Operates at 750 kbps over distances up to 500 m, suitable for large industrial networks.
-
24 VDC Rated Operation: Supports a stable and noise-resistant 24 VDC control voltage for industrial automation systems.
-
Long Mechanical and Electrical Life: Offers 20 million mechanical cycles and over 100,000 electrical cycles under rated load.
-
Compact Design with DIN Rail Mounting: Slim profile for control cabinet installation, utilizing screw terminal connections.
-
Versatile Switching Power: Provides up to 730 VA AC or 90 W DC switching capacity per output channel.
-
Minimum Load Support: Capable of controlling loads as low as 10 mA at 5 VDC, suitable for sensitive electronics.
The SRT2-ROC16 delivers the reliability and precision required for distributed relay control in compact, fast-responding, and space-limited industrial systems.
