ST9160B1050 | Honeywell Furnace Control Circuit Board
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: ST9160B1050
Description
ST9160B1050 is an integrated furnace control board used to regulate the operation of gas heating systems. It manages the ignition sequence, blower control, and safety interlocks within HVAC units. Designed for 24V operation, it supports single-phase systems in residential and light commercial applications.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Honeywell |
| Category |
HVAC & Refrigeration
|
| Part Number | ST9160B1050 |
| Subcategory | Furnace Control Board |
| Type | Integrated Furnace Control Board |
| Voltage | 24 V AC |
| Amperage | 50 A |
| Power Phase | Single-phase |
| Compatible Brands | Honeywell, Heil, American Standard, Carrier, York, Bryant, Trane, Ducane, Luxaire, Airease |
| Power Source | Gas |
| Material | Plastic |
| Dimensions (L x W x H) | 8 in x 8 in x 1 in |
| Application | Gas furnaces, split HVAC systems, central heaters |
| Weight | 1 lb (0.45 kg) |
Information About ST9160B1050
The ST9160B1050 is a universal integrated furnace control board manufactured by Honeywell. It is designed to replace a variety of OEM boards in gas furnaces and is compatible with split systems and central HVAC units. The board provides fan control, ignition management, and diagnostic feedback, and is built to operate on a 24V supply with 50A rated amperage handling. Its durable plastic housing and standardized mounting make it a reliable retrofit component for many heating systems.
Key Features:
- Universal Compatibility: Designed to replace many OEM furnace boards across various brands.
- 24V Operation: Operates reliably on 24V AC control voltage for standard HVAC systems.
- Gas Furnace Application: Optimized for control of gas-powered heating equipment.
- Single Phase System Support: Engineered for 1-phase residential and light commercial systems.
- High Current Rating: Supports up to 50A output to accommodate blower and igniter circuits.
- Plastic Housing: Lightweight and durable enclosure with secure mounting.
- Compact Dimensions: Sized at 8" x 8" x 1", ideal for constrained HVAC compartments.
- Diagnostic Capabilities: Often paired with LED fault indicators or remote status feedback.
- Multiple Compatible Models: Matches models HQI012358HW, ST9160BI050, and others.
The ST9160B1050 delivers the reliability and system coordination required for modern gas furnace control.
