Part #: ST9160B1076 Manufactured by: Honeywell
Regular price
$355.00
Sale price
$355.00
Regular price
1 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The ST9160B1076 is a versatile Honeywell universal furnace fan timer, engineered for efficient control of single-stage HVA...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: ST9160B1076
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Honeywell
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: ST9160B1076

Description / Specifications

Description

The ST9160B1076 is a universal electronic fan timer designed for single-stage gas furnaces with PSC blower and inducer motors. It integrates fan and inducer control with diagnostic capabilities for enhanced serviceability. Suitable for retrofit or OEM applications, the board offers flexible mounting and easy wiring with clearly labeled terminals.





Technical Specifications

Condition New/Never Used Surplus
Brand Honeywell
Category
Controls & Indicators
Part Number ST9160B1076
Subcategory Timer / Counter
Control Type Furnace Electronic Fan Timer
Stages Supported Single Stage
Input Voltage 24 VAC, 60 Hz
Line Voltage 115–230 VAC, 60 Hz
Motor Compatibility PSC Inducer and Blower Motors
Operating Temperature -40°F to 175°F (-40°C to 80°C)
Humidity Range 5% to 95% RH (non-condensing)
Diagnostics Tri-color LED and fault recall button
Mounting Options 6-hole universal mounting
Terminal Types 1/4" and 3/16" transformer terminals
Dimensions (inches) 5.0" W x 7.0" L x 1.5" D
Material Plastic
Compatible Systems Central Furnace, Heat Pump, Split Systems
Weight 1.00 lb (0.45 kg)





Information About ST9160B1076

The ST9160B1076 is a Honeywell furnace control board used in various residential HVAC systems, including central furnaces and split systems. It features input control voltage of 24 VAC and manages line voltages of 115–230 VAC to coordinate blower and inducer fan operation. The unit supports both non-integrated furnace controls and intelligent gas valves and is designed with wide compatibility in mind. With its tri-color LED diagnostic system and exclusive fault recall, the ST9160B1076 is ideal for technicians seeking efficient installation and service diagnostics.

Key Features:

  • Universal Application: Designed for use with single-stage furnaces and PSC motors.
  • Control Flexibility: Compatible with non-integrated furnace controls and smart gas valves.
  • Voltage Range: Operates on 24 VAC input and supports 115–230 VAC line voltage.
  • Multiple Mounting Options: Six mounting holes accommodate various installation layouts.
  • Labeled Terminals: Matches labeling on most common replacement boards for easy wiring.
  • Fault Diagnostics: Tri-color LED displays operational status and fault codes.
  • Recall Button: Built-in button recalls the last fault for troubleshooting after power loss.
  • Durable Construction: Operates in environments from -40°F to 175°F with up to 95% humidity.
  • Compact Size: Dimensions of 5.0" W x 7.0" L x 1.50" D suit most furnace compartments.
  • OEM Compatibility: Commonly used in systems by Heil and other major brands.

The ST9160B1076 delivers the reliability and diagnostics essential for modern furnace system control and service.
