SV9501M2056 | Honeywell Smart Gas Valve 24 V 50/60 Hz
- Regular price
- $388.00
- Sale price
- $388.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: SV9501M2056
Description
The Honeywell SV9501M2056 is a Smart Gas Valve designed for use in residential and light commercial furnaces. Operating at 24 VAC and 50/60 Hz, it integrates gas flow control and electronic system management into one compact unit, providing reliable ignition, flame sensing, and modulation for efficient furnace operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | Gas Controls |
| Part Number | SV9501M2056 |
| Subcategory | Smart Gas Valves |
| Type | Integrated furnace control gas valve |
| Power Supply | 24 VAC, 50/60 Hz |
| Control System | Electronic furnace control (SmartValve system) |
| Gas Type | Natural or LP gas (conversion kits available) |
| Valve Operation | Single-stage control |
| Pressure Regulation | Factory set for typical furnace manifold pressure |
| Ignition Type | Hot surface or direct spark ignition |
| Flame Detection | Integrated flame sensing via control circuit |
| Connection Type | Threaded inlet and outlet (standard NPT fittings) |
| Mounting Orientation | Upright or as specified by installation guide |
| Safety Features | Integrated safety shutoff, self-diagnostics, lockout on flame failure |
| Electrical Interface | Multi-pin quick-connect terminal block |
| Frequency | 50/60 Hz |
| Ambient Temperature Range | 0°F to +175°F (-18°C to +79°C) |
| Body Material | Die-cast aluminum housing |
| Certifications | UL, CSA listed |
| Applications | Residential gas furnaces, boilers, and HVAC heating systems |
| Diagnostic Capability | LED and system fault feedback (via compatible controller) |
| Maintenance | Field replaceable with compatible SmartValve system |
| Weight | 1.79 lbs (approx. 0.81 kg) |
Information About SV9501M2056
The Honeywell SV9501M2056 belongs to the SmartValve family of advanced gas control systems, engineered to combine safety, ignition, and gas regulation into a single integrated module. Designed for modern furnaces, it provides both system control and gas flow management for consistent and efficient heating performance. The SmartValve communicates with the furnace control board to manage ignition timing, flame sensing, and gas valve operation, ensuring precise combustion control. The 24 VAC power operation makes it compatible with standard furnace control circuits. With self-diagnostic capabilities and integrated safety shutoff features, the SV9501M2056 simplifies installation, reduces wiring complexity, and improves overall system reliability.
Key Features:
- Integrated Smart Control: Combines gas regulation, ignition sequencing, and flame sensing in one compact control valve for simplified furnace operation.
- Reliable 24 VAC Operation: Designed to interface directly with standard furnace control circuits for consistent ignition and safety performance.
- Advanced Safety Mechanisms: Includes automatic shutoff and system lockout functions in case of ignition or flame failure.
- Self-Diagnostic Feedback: Works with compatible Honeywell controllers to provide diagnostic codes and LED fault indication.
- Versatile Ignition Compatibility: Supports both hot surface and direct spark ignition systems for flexible application use.
- Durable Construction: Die-cast aluminum housing ensures mechanical strength and long-lasting operation in HVAC environments.
- Stable Pressure Regulation: Factory-calibrated manifold pressure settings provide steady and efficient gas flow.
- Compact Modular Design: Reduces installation time and wiring complexity by integrating multiple control functions into one unit.
- Broad System Compatibility: Suitable for use in a wide range of residential and light commercial furnaces and heating appliances.
- UL/CSA Certified: Meets international safety and performance standards for gas-fired heating systems.
The SV9501M2056 delivers the reliability and precision required for safe and efficient operation in Honeywell furnace and HVAC control systems.
