Product Description P/N: SVQ-10-PNL
Description
The Lutron SVQ-10-PNL is a 120 V power supply panel designed for use with Sivoia QED automated shading systems. It converts 120 V AC to 24 V DC power for up to ten Electronic Drive Units (EDUs), supporting a total load of 8 A. This panel enables centralized and reliable power delivery with integrated communication link terminals.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Lutron |
| Category | Power Supplies |
| Part Number | SVQ-10-PNL |
| Subcategory | Shading System Power Panels |
| Input Voltage | 120 V AC |
| Output Voltage | 24 V DC |
| Total Output Current | 8 A max (combined across all outputs) |
| Output per EDU | 3 A max per output terminal |
| Number of Outputs | Supports up to 10 EDUs |
| Mounting Type | Surface or recessed (hardware not included) |
| Enclosure Type | Vented steel panel, black finish |
| Wiring Terminals | 10–18 AWG terminal blocks, torque 3.5–5 in-lbs |
| Communication Link | 4-conductor foil-shielded cabling required |
| Ambient Temperature | 32–104°F (0–40°C) |
| Humidity Range | 0–90% non-condensing |
| Indoor Use | Yes |
| Safety Notes | Requires breaker lockout; air vents must remain unobstructed |
| Certifications | UL Listed, CE compliant |
| Weight | 10.5 lb |
Information About SVQ-10-PNL
The SVQ-10-PNL is part of the Sivoia QED series of power panels used to distribute power and communication signals to automated window shade systems. Designed for both surface and recessed mounting, the unit features terminal blocks for 120 V input and multiple 24 V DC outputs. It supports up to ten Sivoia QED drive units, each with shade sizes up to 100 sq ft (or 225 sq ft for high-torque units). This panel includes internal strain reliefs and knock-outs for flexible field wiring and interconnection with other panels.
Key Features:
- 10-Unit Capacity: Powers up to ten Sivoia QED electronic drive units.
- Voltage Conversion: Converts 120 V AC to 24 V DC regulated output.
- Max Current Output: Supplies up to 3 A per output, 8 A total across all outputs.
- Mounting Options: Supports both surface and recessed wall installation.
- Communication Link: Integrated low-voltage terminals for EDU and inter-panel communication.
- Ventilated Design: Air-cooled with vented cover; must not be obstructed.
- Safety Features: Terminal block torque limits and breaker lockout for safe installation.
- Application Use: Ideal for indoor commercial or residential QED shade systems.
The SVQ-10-PNL delivers the stable low-voltage power and flexible integration required for centralized Sivoia QED shade automation systems.
