T1F-08DA-2 | Automation Direct 5-10VDC Analog Output Module

Description

The T1F-08DA-2 is a 5-10VDC analog output module from Automation Direct. It is designed to provide analog output signals for controlling devices within a specified voltage range, making it suitable for various industrial control applications.

Technical Specifications

Information About T1F-08DA-2

The T1F-08DA-2 is a Terminator Analog Output Module designed by Automation Direct for use in PLCs and machine control systems. This module falls under the category of PLCs/Machine Control and is specifically classified in the subcategory of PLC Module/Rack, indicating its primary role in expanding the capabilities of programmable logic controllers by providing high-precision analog output functionality. It is engineered to meet the demands of various industrial automation applications, offering reliable and accurate analog signal output to control a wide range of devices and processes.

The T1F-08DA-2 features 8 output channels, allowing it to handle multiple signals simultaneously. Each channel is capable of outputting analog voltage signals, making this module ideal for applications where precise control over voltage levels is required. The 8-channel design provides flexibility and scalability, enabling users to control multiple devices or processes from a single module, which reduces the need for additional hardware and simplifies system architecture.

This module offers a 12-bit resolution, ensuring high accuracy in the analog output signals. A 12-bit resolution means that the module can produce 4,096 discrete output levels for each signal, allowing for fine-grained control over the voltage output. This level of precision is essential in applications where small changes in voltage can have significant effects, such as in process control, automated testing, and precision instrumentation. The high resolution of the T1F-08DA-2 helps ensure that the output signals are accurate and consistent, which is critical for maintaining the reliability and performance of the overall control system.

The T1F-08DA-2 supports multiple output voltage signal ranges, including 0-5 VDC, 0-10 VDC, +/- 5 VDC, and +/- 10 VDC. This versatility allows the module to be used in a wide range of applications, as it can easily adapt to different voltage requirements. Whether the task involves driving standard 0-10 VDC actuators or more specialized equipment that requires bipolar voltage signals, the T1F-08DA-2 can accommodate the needs of the system. This flexibility simplifies integration and reduces the need for additional conversion equipment, saving both time and cost.

The module operates on a 24 VDC power supply, a common voltage in industrial control systems. The use of a 24 VDC power supply ensures that the T1F-08DA-2 can be easily integrated into existing control systems that use standard power supplies, enhancing its compatibility and ease of installation. The power supply requirement also contributes to the module’s reliability, as 24 VDC systems are typically robust and resilient against power fluctuations, ensuring stable operation.

The T1F-08DA-2 is designed to be used within Terminator I/O systems, making it compatible with a wide range of Automation Direct PLCs and controllers. Its design facilitates easy installation into Terminator I/O racks, providing a streamlined solution for expanding the analog output capabilities of a control system. The module’s form factor and connector design ensure that it can be quickly installed or replaced, minimizing downtime and making it a convenient choice for both new installations and system upgrades.

In summary, the Automation Direct T1F-08DA-2 Terminator Analog Output Module is a versatile and precise solution for adding analog output functionality to PLC-based control systems. With its 8-channel design, 12-bit resolution, and support for various voltage signal ranges, it offers the flexibility and accuracy needed for a wide range of industrial applications. The module’s compatibility with 24 VDC power supplies and Terminator I/O systems further enhances its appeal, making it an efficient and reliable choice for process control, automation, and other precision applications.

Manufacturer information

Automation Direct is a well-established supplier of industrial automation and control products. Founded in 1994, the company offers a wide range of cost-effective, user-friendly solutions, including PLCs, HMIs, sensors, and more, catering to diverse automation needs globally.
