TCSEGDB23F24FA | Schneider Electric Modicon X80 Modbus Plus Proxy Module For M340 And M580
- Regular price
- $1,422.00
- Sale price
- $1,422.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TCSEGDB23F24FA
Description
The Schneider Electric TCSEGDB23F24FA is a Modbus Plus proxy module designed to enable communication between modern PLC systems and legacy Modbus Plus devices. It supports seamless data exchange without requiring changes to existing Modbus Plus applications. This module is used within Modicon X80 architectures for industrial automation systems.
Technical Specifications
| Condition | New / Never Used Surplus |
| Brand | Schneider Electric |
| Category | PLCs / Machine Control |
| Part Number | TCSEGDB23F24FA |
| Subcategory | PLC Module / Rack |
| Product Range | Modicon X80 |
| Product Type | Modbus Plus Proxy Module |
| Compatible PLC Platforms | Modicon M340, Modicon M580 |
| Number of Supported Slaves | 128 |
| Ethernet Interface | 10/100BASE-T |
| Ethernet Ports | 2 × RJ45 (Modbus TCP) |
| Modbus Plus Interface | 2 × SUB-D 9 |
| Physical Interface | Ethernet TCP/IP, RS485 |
| Current Consumption | 300 mA at 24 V DC (external) |
| Module Format | Standard |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -45 to 85 °C |
| Relative Humidity | 10 to 95 % Non-Condensing |
| Maximum Operating Altitude | ≤ 2000 m |
Information About TCSEGDB23F24FA
The TCSEGDB23F24FA is part of the Schneider Electric Modicon X80 platform, developed to bridge modern Ethernet-based PLC systems with installed Modbus Plus networks. It functions as a proxy, allowing Modicon M340 and M580 controllers to communicate transparently with Modbus Plus devices without modifying existing field applications. The module integrates Ethernet TCP/IP and Modbus Plus connectivity within a single hardware unit. It is commonly deployed in process industries, infrastructure, manufacturing, water treatment, renewable energy systems, and machine automation where legacy Modbus Plus equipment remains in operation.
Key Features:
- Modbus Plus Proxy Functionality: Enables transparent communication between modern PLCs and existing Modbus Plus devices without application changes.
- Broad PLC Compatibility: Designed for seamless integration with Modicon M340 and Modicon M580 controllers.
- Dual Ethernet Connectivity: Provides two RJ45 ports supporting Modbus TCP over 10/100BASE-T networks.
- Integrated Modbus Plus Interfaces: Includes two SUB-D 9 connectors for direct Modbus Plus communication.
- High Network Capacity: Supports up to 128 Modbus Plus slave devices within a single system architecture.
- Industrial Environmental Rating: Designed for reliable operation across wide temperature and humidity ranges.
- Flexible Installation Options: Suitable for rack or DIN rail mounting within Modicon X80 control systems.
The TCSEGDB23F24FA delivers the reliability and precision required for integrating legacy Modbus Plus networks into modern Schneider Electric PLC automation architectures.
