TG3223R | General Electric 100 A Fusible General-Duty Safety Switch, NEMA 3R, 240 VAC
- Regular price
- $149.00
- Sale price
- $149.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: TG3223R
Description
The GE TG3223R is a 100 A general-duty fusible safety switch designed for reliable disconnect and overcurrent protection in residential and light commercial installations. Built with a NEMA 3R outdoor-rated enclosure, it provides dependable switching performance for 240 VAC single-phase systems requiring secure isolation and fuse protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | GE |
| Category | Electrical Safety & Disconnects |
| Part Number | TG3223R |
| Subcategory | General-Duty Fusible Safety Switches |
| Series | Spec-Setter™ TG Series |
| Type | Fusible, General Duty |
| Amperage Rating | 100 A |
| Voltage Rating | 240 VAC, 1-phase |
| Frequency Rating | 50/60 Hz |
| Number of Poles | 2 |
| Number of Wires | 3 |
| Enclosure Rating | NEMA 3R (Outdoor) |
| Material | Steel |
| Mounting Type | Surface mount |
| Actuator Type | Handle |
| Horsepower Rating | 7.5 hp (standard fuse), 15 hp (time delay) |
| Fusing | Fusible; supports Class H, K, J, R fuses |
| Short Circuit Current Rating | 10 kA standard; up to 100 kA with Class R kit |
| Wire Range (Cu/Al) | 10–1/0 AWG |
| Temperature Rating | 60/75°C conductor rating |
| GSA Compliance | Yes |
| Certifications | UL Listed, cUL Listed |
| Dimensions | 21.05 in H × 9.32 in W × 5.04 in D |
| Weight | 17.0 lb |
Information About TG3223R
The TG3223R belongs to GE’s Spec-Setter™ TG Series, a line of general-duty safety switches engineered for straightforward installation and long-term serviceability. This model supports two-pole, three-wire configurations and accommodates Class H, K, J, or R fuses depending on application needs. Its quick-make, quick-break mechanism ensures consistent switching action, while the steel enclosure and cover interlock enhance safety during operation. Designed to meet UL and cUL requirements, the switch is suitable for service entrance use when installed according to NEC guidelines.
Key Features:
- 100 A Fusible Disconnect: Provides reliable overcurrent protection for single-phase 240 VAC circuits.
- Quick-Make/Quick-Break Mechanism: Ensures positive switching action with clear ON/OFF indication.
- NEMA 3R Enclosure: Outdoor-rated steel housing designed for weather-resistant surface mounting.
- Support for Multiple Fuse Classes: Compatible with H, K, J, and R fuses to match application demands.
- Integrated Cover Interlock: Prevents access when the switch is in the ON position for added operator safety.
- Visible Blade Contacts: Allows quick confirmation of switch status during maintenance.
- High SCCR Capability: Standard 10 kA rating, up to 100 kA when paired with Class R fuse kits.
- Self-Leveling Mounting System: Simplifies installation and improves alignment on uneven surfaces.
The TG3223R delivers the reliability and precision required for safe electrical isolation and overcurrent protection in general-duty applications.
