THED124025 | General Electric 25A 2-Pole 480V Thermal-Magnetic Molded Case Circuit Breaker
- Regular price
- $699.00
- Sale price
- $699.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: THED124025
Description
The General Electric THED124025 is a 2-pole molded case circuit breaker designed to provide dependable overcurrent protection in 480-volt systems. With a 25-amp rating and a thermal-magnetic trip unit, it delivers accurate response to overload and fault conditions. This breaker is suited for commercial and industrial distribution equipment requiring a compact, bolt-on protective device with high interrupting capacity.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | General Electric |
| Category | Circuit Breaker |
| Part Number | THED124025 |
| Subcategory | Molded Case |
| Series | E-150 Line |
| Frame Type | THE / TED Frame |
| Type | THED |
| Amperage Rating | 25A |
| Voltage Rating | 480 VAC |
| Poles | 2 |
| Phase | 1 |
| Interrupting Rating | 25kA @ 480V |
| Trip Unit | Thermal Magnetic |
| Trip Functions | Long-Time & Instantaneous |
| Mounting Type | Bolt-On |
| Connection Type | Feed-Thru |
| Terminal Type | Line and Load Side Lugs |
| Temperature Rating | –25°C to 70°C |
| Certifications | UL 489, ANSI C37 |
| Weight | 2 lbs |
Information About THED124025
The THED124025 is part of GE’s E-150 Line series, built on the THE/TED frame platform for compatibility with a wide range of GE panelboards and switchboards. Its molded case design ensures durability, while the thermal-magnetic trip unit provides long-time and instantaneous protection tailored for demanding electrical environments. The breaker supports bolt-on mounting, making it suitable for installations where secure mechanical fastening is required. Its 25kA interrupting rating at 480 volts allows it to perform reliably in high-fault industrial applications.
Key Features:
- 25A Thermal-Magnetic Trip: Ensures precise overload and short-circuit protection.
- 2-Pole Configuration: Protects two conductors in single-phase 480V systems.
- High Interrupting Rating: Rated at 25kA at 480V for robust fault-handling capability.
- Bolt-On Mounting: Provides secure mechanical installation in compatible GE distribution panels.
- E-150 Line / THE Frame Construction: Ensures compatibility with GE’s industrial circuit protection platforms.
- UL 489 and ANSI Certified: Meets industry standards for electrical safety and performance.
- Wide Temperature Operating Range: Suitable for environments from –25°C to 70°C.
- Feed-Thru Terminal Design: Supports straightforward line and load lug connections.
The THED124025 delivers the reliability and precision required for dependable molded case circuit protection in commercial and industrial power systems.
