Part #: THQB2130 Manufactured by: General Electric
Regular price
$57.00
Sale price
$57.00
Regular price
4 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The THQMV200WL is a General Electric circuit breaker designed for top-feed main applications within PowerMark Gold systems...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Meta Pay
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: THQB2130
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for General Electric
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.
THQB2130 | General Electric | Circuit Breaker
    THQB2130 | General Electric | Circuit Breaker
THQB2130 | General Electric | Circuit Breaker

Product Description P/N: THQB2130

Description / Specifications

Description

The THQB2130 is a circuit breaker manufactured by General Electric, belonging to the THQB type. It operates with 2 poles in single-phase systems, rated at 30A and 240V. With an interrupting capacity of 10kA at 240V and a temperature rating of 40°C, it ensures effective circuit interruption under specified conditions. The circuit breaker is UL listed, indicating compliance with safety standards.

Utilizing Bolt-On mounting, the THQB2130 employs Thermal Magnetic technology and features Long-Time and Instantaneous trip functions. Additionally, it is equipped with load side lug terminals for secure electrical connections. This molded case circuit breaker is designed to offer reliable circuit protection in various electrical applications.





Technical Specifications



Specifications



Part #

THQB2130

Manufacturer

GENERAL ELECTRIC

Category

Circuit Breaker

Subcategory

Load Center Circuit Breaker Trip Style Non-Interchangeable

Frame Type

Q-Line

Amperage

30 A

System Voltage

120 Vac, 120/240 Vac

Poles

2

Trip Function

LI

Continuous Current Rated

Standard

120 Vac Interrupting Rating

10 KAIC

120/240 Vac Interrupting Rating

10 KAIC

Suitable for Reverse Feed

Yes

Wire Range (Cu/Al)

14-8 kcmil / 12-8 kcmil

Long Time

Fixed

Instantaneous

Fixed

Protective Relays

No

Current Metering

No

Special Markings

HACR

GSA Compliance

Yes






Information About THQB2130



The THQB2130 is a circuit breaker manufactured by General Electric, designated as type THQB. It operates with 2 poles in single-phase systems, with a current rating of 30A and a voltage rating of 240V. With an interrupting capacity of 10kA at 240V and a maximum operating temperature of 40°C, it ensures effective circuit interruption within specified conditions.

This circuit breaker is UL listed, indicating its compliance with safety standards and regulations. It utilizes Bolt-On mounting for secure installation. Employing Thermal Magnetic technology, it incorporates Long-Time and Instantaneous trip functions, enhancing its ability to respond to electrical abnormalities promptly. Additionally, it features load side lug terminals, facilitating secure electrical connections.

The THQB2130 serves as a molded case circuit breaker, offering reliable circuit protection in various electrical applications. Its design and specifications make it suitable for use in residential, commercial, and industrial settings where circuit protection is paramount.





Manufacturer information

General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
Description / Specifications

Description

The THQB2130 is a circuit breaker manufactured by General Electric, belonging to the THQB type. It operates with 2 poles in single-phase systems, rated at 30A and 240V. With an interrupting capacity of 10kA at 240V and a temperature rating of 40°C, it ensures effective circuit interruption under specified conditions. The circuit breaker is UL listed, indicating compliance with safety standards.

Utilizing Bolt-On mounting, the THQB2130 employs Thermal Magnetic technology and features Long-Time and Instantaneous trip functions. Additionally, it is equipped with load side lug terminals for secure electrical connections. This molded case circuit breaker is designed to offer reliable circuit protection in various electrical applications.





Technical Specifications



Specifications



Part #

THQB2130

Manufacturer

GENERAL ELECTRIC

Category

Circuit Breaker

Subcategory

Load Center Circuit Breaker Trip Style Non-Interchangeable

Frame Type

Q-Line

Amperage

30 A

System Voltage

120 Vac, 120/240 Vac

Poles

2

Trip Function

LI

Continuous Current Rated

Standard

120 Vac Interrupting Rating

10 KAIC

120/240 Vac Interrupting Rating

10 KAIC

Suitable for Reverse Feed

Yes

Wire Range (Cu/Al)

14-8 kcmil / 12-8 kcmil

Long Time

Fixed

Instantaneous

Fixed

Protective Relays

No

Current Metering

No

Special Markings

HACR

GSA Compliance

Yes






Information About THQB2130



The THQB2130 is a circuit breaker manufactured by General Electric, designated as type THQB. It operates with 2 poles in single-phase systems, with a current rating of 30A and a voltage rating of 240V. With an interrupting capacity of 10kA at 240V and a maximum operating temperature of 40°C, it ensures effective circuit interruption within specified conditions.

This circuit breaker is UL listed, indicating its compliance with safety standards and regulations. It utilizes Bolt-On mounting for secure installation. Employing Thermal Magnetic technology, it incorporates Long-Time and Instantaneous trip functions, enhancing its ability to respond to electrical abnormalities promptly. Additionally, it features load side lug terminals, facilitating secure electrical connections.

The THQB2130 serves as a molded case circuit breaker, offering reliable circuit protection in various electrical applications. Its design and specifications make it suitable for use in residential, commercial, and industrial settings where circuit protection is paramount.





Manufacturer information

General Electric (GE) is a multinational conglomerate founded in 1892, based in the United States. It operates in various industries, including aviation, healthcare, renewable energy, and power. GE is known for its innovations in technology, manufacturing, and infrastructure solutions.
