TM262L10MESE8T | Schneider Electric Modicon M262 IIoT-Ready Logic/Motion Controller with 8 Integrated I/Os
- Regular price
- $1,579.00
- Sale price
- $1,579.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TM262L10MESE8T
Description
The Schneider Electric TM262L10MESE8T is a Modicon M262 series logic and motion controller featuring integrated IIoT capabilities and embedded Ethernet-based communication. It includes 4 digital inputs and 4 digital outputs, operating from a 24VDC supply for compact machine-control applications. With built-in EtherNet/IP, Modbus TCP, RS-232, and RS-485 communication, the TM262L10MESE8T provides a versatile automation platform for high-performance industrial systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Controls & Indicators |
| Part Number | TM262L10MESE8T |
| Subcategory | CPU/Control Board |
| Series | TM / Modicon M262 |
| Type | Logic & Motion Controller |
| Primary Application | Machine automation, IIoT systems |
| Supply Voltage | 19–30 VDC (24 VDC nominal) |
| Integrated Inputs | 4 digital inputs (24VDC, sink) |
| Integrated Outputs | 4 digital outputs (24VDC, 5A, source) |
| Communication Ports | EtherNet/IP, Modbus TCP, RS-232, RS-485 |
| Additional Ethernet Networks | Up to 3 |
| Accuracy | ±0.1% |
| Power Rating | 82 W |
| Amperage Rating | 40 A (as listed) |
| Memory | 256 MB RAM for applications/data |
| Mounting Type | DIN rail or panel mount |
| Terminal Type | Spring clamp (removable block) |
| Degree of Protection | IP20 |
| Operating Temperature | –20 to 60 °C (–4 to +140 °F) |
| Dimensions | 100 mm (H) × 125 mm (W) × 90 mm (D) |
| Supported Protocols | EtherNet/IP, Modbus TCP, ASCII, Machine Expert |
| Expansion Support | TM3 I/O modules, CANopen module |
| I/O System Connectivity | One I/O bus, one I/O port |
| Certifications | CE, cULus HazLoc, RCM, EAC, Achilles L2, UL 61010-1/-2-201, EN 61131-2 |
Information About TM262L10MESE8T
The TM262L10MESE8T belongs to the Modicon M262 controller family, offering integrated logic, motion, and IIoT connectivity within a compact modular CPU module. Its design includes a dual-core processor, local spring-terminal connections, and support for expansion via TM3 I/O modules and CANopen communication options. The controller supports up to three Ethernet networks and multiple industrial protocols, enabling scalable architectures suitable for modern machine automation. Typical usage includes standalone or distributed machine control requiring synchronized motion capability, cloud connectivity, secure communication, and deterministic control performance.
Key Features
- Integrated I/Os: Includes 4 digital inputs (24VDC, sink) and 4 digital outputs (24VDC, 5A, source).
- IIoT-ready platform: Supports encrypted communication and direct cloud connectivity.
- Multi-network support: Features EtherNet/IP, Modbus TCP, RS-232, and RS-485 communication.
- High-performance processing: Dual-core architecture with 5 ns per instruction execution.
- Flexible mounting: Supports DIN rail or panel installation with removable spring terminal blocks.
- Wide power tolerance: Operates from a 19–30VDC supply (24VDC nominal).
- Industrial environmental rating: Rated IP20 and supports ambient temperatures from –20 to 60 °C.
- Modular expansion: Compatible with TM3 I/O modules and CANopen communication options.
The TM262L10MESE8T delivers the reliability and precision required for connected machine automation and high-performance control applications.
Description
The Schneider Electric TM262L10MESE8T is a Modicon M262 series logic and motion controller featuring integrated IIoT capabilities and embedded Ethernet-based communication. It includes 4 digital inputs and 4 digital outputs, operating from a 24VDC supply for compact machine-control applications. With built-in EtherNet/IP, Modbus TCP, RS-232, and RS-485 communication, the TM262L10MESE8T provides a versatile automation platform for high-performance industrial systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | Controls & Indicators |
| Part Number | TM262L10MESE8T |
| Subcategory | CPU/Control Board |
| Series | TM / Modicon M262 |
| Type | Logic & Motion Controller |
| Primary Application | Machine automation, IIoT systems |
| Supply Voltage | 19–30 VDC (24 VDC nominal) |
| Integrated Inputs | 4 digital inputs (24VDC, sink) |
| Integrated Outputs | 4 digital outputs (24VDC, 5A, source) |
| Communication Ports | EtherNet/IP, Modbus TCP, RS-232, RS-485 |
| Additional Ethernet Networks | Up to 3 |
| Accuracy | ±0.1% |
| Power Rating | 82 W |
| Amperage Rating | 40 A (as listed) |
| Memory | 256 MB RAM for applications/data |
| Mounting Type | DIN rail or panel mount |
| Terminal Type | Spring clamp (removable block) |
| Degree of Protection | IP20 |
| Operating Temperature | –20 to 60 °C (–4 to +140 °F) |
| Dimensions | 100 mm (H) × 125 mm (W) × 90 mm (D) |
| Supported Protocols | EtherNet/IP, Modbus TCP, ASCII, Machine Expert |
| Expansion Support | TM3 I/O modules, CANopen module |
| I/O System Connectivity | One I/O bus, one I/O port |
| Certifications | CE, cULus HazLoc, RCM, EAC, Achilles L2, UL 61010-1/-2-201, EN 61131-2 |
Information About TM262L10MESE8T
The TM262L10MESE8T belongs to the Modicon M262 controller family, offering integrated logic, motion, and IIoT connectivity within a compact modular CPU module. Its design includes a dual-core processor, local spring-terminal connections, and support for expansion via TM3 I/O modules and CANopen communication options. The controller supports up to three Ethernet networks and multiple industrial protocols, enabling scalable architectures suitable for modern machine automation. Typical usage includes standalone or distributed machine control requiring synchronized motion capability, cloud connectivity, secure communication, and deterministic control performance.
Key Features
- Integrated I/Os: Includes 4 digital inputs (24VDC, sink) and 4 digital outputs (24VDC, 5A, source).
- IIoT-ready platform: Supports encrypted communication and direct cloud connectivity.
- Multi-network support: Features EtherNet/IP, Modbus TCP, RS-232, and RS-485 communication.
- High-performance processing: Dual-core architecture with 5 ns per instruction execution.
- Flexible mounting: Supports DIN rail or panel installation with removable spring terminal blocks.
- Wide power tolerance: Operates from a 19–30VDC supply (24VDC nominal).
- Industrial environmental rating: Rated IP20 and supports ambient temperatures from –20 to 60 °C.
- Modular expansion: Compatible with TM3 I/O modules and CANopen communication options.
The TM262L10MESE8T delivers the reliability and precision required for connected machine automation and high-performance control applications.
