TQD22150 | General Electric Q-Line 150A 2-Pole 240V Bolt-On Thermal Magnetic Circuit Breaker
- Regular price
- $629.00
- Sale price
- $629.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TQD22150
Description
The General Electric TQD22150 is a 150-amp, 2-pole molded case circuit breaker designed for 120/240-volt single-phase electrical systems. It features a fixed thermal-magnetic, non-interchangeable trip unit that provides dependable Long-Time and Instantaneous protection. With a 10 kA interrupting rating at 240V, the TQD22150 supports standard residential, commercial, and light industrial distribution applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | General Electric |
| Category | Circuit Breaker |
| Part Number | TQD22150 |
| Subcategory | Molded Case Circuit Breaker |
| Manufacturer | General Electric |
| Type | TQD |
| Frame | Q-Line |
| Voltage Rating | 120/240 VAC (240V max) |
| Amperage Rating | 150 A |
| Poles | 2 |
| Phase | 1-Phase |
| Trip Type | Internal Common, Non-Interchangeable, Thermal Magnetic |
| Functions | LI – Long-Time, Instantaneous |
| Interrupt Rating | 10 kA @ 240V |
| Connection Type | Bolt-On |
| Terminal Type | Load-Side Lugs |
| Wire Size Range | 1 AWG – 300 MCM |
| Mounting Type | Panelboard |
| Dimensions | 6-9/16" L × 2-3/4" W × 2-5/8" D |
| Protection Type | Overload and Short-Circuit |
| Operating Temperature | 40°C |
| Applications | Residential, commercial, and light industrial distribution |
| Certifications | UL Listed (File E-11592) |
| Additional Features | Suitable for reverse-feed applications |
Information About TQD22150
The TQD22150 is part of the General Electric Q-Line family, engineered for panelboard applications requiring bolt-on installation and consistent overcurrent protection. Built with a molded case design, it incorporates an internal common trip mechanism and non-interchangeable thermal-magnetic elements for reliable LI protection. The breaker’s 2-pole configuration supports single-phase systems, while load-side lug terminals ensure secure conductor termination. With a 150-amp rating, 240-volt capability, and a compact Q-Line frame design, it is widely used in distribution panels requiring dependable branch-circuit protection.
Key Features
- 150A molded case breaker: Provides dependable protection for single-phase distribution circuits.
- 2-pole configuration: Supports 120/240-V AC electrical systems.
- Thermal-magnetic trip: Fixed Long-Time and Instantaneous protection for overloads and faults.
- Q-Line molded case design: Compact format for panelboard and switchboard installations.
- Bolt-on mounting: Ensures secure installation in compatible panelboard assemblies.
- Non-interchangeable trip unit: Provides consistent performance and stable calibration.
- 10 kA interrupting rating: Meets standard fault-clearing requirements at 240V.
- Load-side lugs included: Accepts 1 AWG to 300 MCM conductors for installation flexibility.
The TQD22150 delivers the reliability and precision required for dependable overcurrent protection in Q-Line panelboard systems.
