Trane MOT13908 Constant Torque Motor 1/2 HP 230V 1050-400 RPM CCW
- Regular price
- $585.00
- Sale price
- $585.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: MOT13908
Description
The Trane MOT13908 constant torque motor provides efficient and consistent airflow management for residential and commercial HVAC units. Operating on a 230V, 60 Hz single-phase power supply with a 1/2 horsepower output and a variable 1050-400 RPM operating range, this counter-clockwise rotating motor adapts dynamically to system static pressure. Its robust permanent magnet architecture ensures low energy consumption and stable air delivery across varied operating conditions.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Trane |
| Category | Motors/GearBox/Clutch |
| Part Number | MOT13908 |
| Subcategory | Motor |
| Horsepower | 1/2 HP |
| Voltage | 230V |
| Phase | 1-Phase |
| Frequency | 60 Hz |
| Speed Range | 1050 - 400 RPM |
| Technology | Constant Torque (ECM) |
| Rotation | Counter-Clockwise (CCW) |
| Application | HVAC Blower / Air Handler |
| Weight | 5.44 kgs |
Information About MOT13908
The MOT13908 is engineered within Trane's constant torque blower motor series, designed to replace standard induction motors with high-efficiency electronically commutated alternatives. The assembly integrates an electronic control module that automatically modulates torque to maintain proper CFM air volume as duct restriction changes. It features high-grade insulation and precision ball bearings constructed to withstand thermal stress and continuous-duty operating cycles. Counter-clockwise rotation (facing the lead end) and standard mounting geometry ensure direct compatibility with OEM fan housing assemblies and air handlers.
Key Features:
-
Horsepower Output: Delivers a reliable 1/2 HP output rated for continuous HVAC air handling duty.
-
Speed Range: Operates across an adjustable 1050 to 400 RPM band to maintain balanced airflow.
-
Voltage Rating: Built for 230V single-phase 60 Hz electrical systems common in climate control units.
-
Constant Torque Technology: Automatically adjusts motor speed to preserve airflow during static pressure fluctuations.
-
Rotation Direction: Configured for counter-clockwise (CCW) rotation relative to the motor lead end.
-
Energy-Efficient Operation: High-efficiency motor design reduces electrical power draw compared to standard PSC motors.
The MOT13908 delivers the reliability and precision required for demanding HVAC air handler and furnace blower applications.
