TSXPSY8500M | Schneider Electric Power Supply Module 5 VDC, 75 W, 100–240 VAC Input
- Regular price
- $1,979.00
- Sale price
- $1,979.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TSXPSY8500M
Description
The Schneider Electric TSXPSY8500M is a high-performance power supply module engineered for Modicon automation systems, delivering a stable 5 VDC output up to 75 W with secondary sensor support. Designed to handle universal AC input ranges, it ensures reliable power delivery for PLC processors, I/O modules, and automation components in demanding industrial environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Schneider Electric |
| Category | PLCs/Machine Control |
| Part Number | TSXPSY8500M |
| Subcategory | PLC Module/Rack |
| Module Format | Double |
| Product Type | Power Supply Module |
| Primary Voltage | 100–120 VAC (85–140 V), 200–240 VAC (170–264 V) |
| Network Frequency | 50/60 Hz (47–63 Hz limits) |
| Input Current | 1700 mA @ 100 V, 500 mA @ 240 V |
| Inrush Current | 30 A @ 100 V, 60 A @ 240 V |
| I²t on Activation | 15 A²·s @ 100 V, 8 A²·s @ 240 V |
| Secondary Output Power | 75 W @ 5 VDC |
| Secondary Current | 15 A (5 VDC), 1.6 A (24 VDC sensor supply) |
| Total Useful Secondary Power | 100 W at 55 °C with fan, 85 W at 55 °C, 77 W at 60 °C |
| Protection Types | Internal fuse, overload, overvoltage, short-circuit |
| Insulation Resistance | ≥ 100 MΩ primary/ground and primary/secondary |
| Local Signalling | Green LED (24 V sensor voltage), Green LED (OK voltage), Red LED (battery fault) |
| Application | Powering Modicon PLC racks, modules, and sensors |
Information About TSXPSY8500M
The TSXPSY8500M is part of Schneider Electric’s Modicon power supply family, designed to deliver robust and stable power to industrial automation systems. Supporting universal input voltages from 100–240 VAC, it provides flexible deployment across global electrical standards while maintaining consistent 5 VDC output for PLC processors and backplane loads. The module supplies up to 15 A at 5 VDC along with 24 VDC sensor power, allowing it to support both controller electronics and field input devices. Built-in electrical protections—including overload, overvoltage, and short-circuit safeguards—ensure long-term operational reliability. LED indicators offer immediate visual diagnostics for voltage presence and battery condition, helping operators maintain system health.
Key Features:
- Universal 100–240 VAC input: supports global installation while ensuring stable power conversion for industrial automation systems.
- 75 W regulated 5 VDC output: delivers consistent power to PLC CPUs, communication modules, and rack-mounted I/O devices.
- Additional 24 V sensor power: provides 1.6 A to support field sensors without requiring an external supply.
- Multiple protection layers: includes internal fuse, overload, overvoltage, and short-circuit protection for system safety and reliability.
- High insulation resistance: ≥ 100 MΩ isolation between primary/ground and primary/secondary circuits for robust electrical safety.
- LED diagnostics: green and red indicators provide immediate status feedback for voltage availability and battery condition.
- Double-format module design: fits Modicon racks requiring higher capacity and wider installation footprint.
- Reliable operation in industrial environments: maintains up to 100 W useful power at elevated ambient temperatures with cooling support.
The TSXPSY8500M delivers the reliability and precision required for stable PLC power distribution, continuous automation performance, and long-term operation within Modicon control systems.
