VLP-002 | Vesda LaserPLUS Aspirating Smoke Detector with AutoLearn and 4-Pipe Sampling
- Regular price
- $6,999.00
- Sale price
- $6,999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VLP-002
Description
The Vesda® VLP-002 is a LaserPLUS aspirating smoke detector designed for very early warning fire detection in a wide range of applications. Using a high-efficiency aspirator and laser-based technology, it provides reliable detection of smoke concentrations from very low to extremely high levels. This model supports multi-zone air sampling and intelligent configuration for precise and stable performance in critical environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Vesda |
| Category | Flame Safety Products |
| Part Number | VLP-002 |
| Subcategory | Flame Safety Detector |
| Series | VESDA LaserPLUS (VLP) |
| Detection Principle | Laser-based light scattering detection |
| Sensitivity Range | 0.005% to 20% obscuration/m |
| Coverage Area | Up to 2,000 m² (21,500 sq. ft.) |
| Sampling Pipes | Four inlet pipes with individual airflow supervision |
| Alarm Levels | 4 configurable (Alert, Action, Fire 1, Fire 2) |
| Aspirator Type | High-efficiency motorized fan |
| Filtration System | Dual-stage air filter with clean air barrier optics |
| Event Logging | Comprehensive log of alarms, faults, and maintenance events |
| Networking Interface | VESDAnet™ communications protocol |
| Relay Outputs | 7 programmable relays |
| Configuration Tools | AutoLearn™ and Referencing™ functions |
| Mounting Options | Wall or recessed mounting |
| Power Supply | 24 VDC (nominal) |
| Dimensions | 7.00 × 8.00 × 10.00 in |
| Weight | 5 lbs |
Information About VLP-002
The VLP-002 is part of the VESDA LaserPLUS (VLP) series, which represents the core of the VESDA air sampling smoke detection range. It operates by continuously drawing air from up to four sampling pipes into a dual-stage filtration and laser detection chamber. The detector features AutoLearn™ and Referencing™ functions to automatically optimize alarm thresholds and compensate for environmental variations. Through VESDAnet™ networking, the VLP-002 integrates easily into complex detection systems for centralized monitoring, configuration, and event logging, making it ideal for large facilities requiring high-sensitivity smoke detection.
Key Features:
- Laser-Based Detection: Class 1 laser technology enables detection of extremely small smoke particles with high accuracy.
- Wide Sensitivity Range: Covers 0.005% to 20% obscuration per meter for flexible application use.
- Multi-Pipe Sampling: Supports up to four air sampling inlets with individual airflow supervision.
- High-Efficiency Aspirator: Ensures consistent airflow across all sampling points for reliable performance.
- AutoLearn™ Function: Automatically configures alarm thresholds based on environmental conditions.
- Referencing™ Capability: Compensates for external air quality changes to prevent false alarms.
- Dual-Stage Air Filtration: Protects optics with coarse and ultra-fine filtering for extended service life.
- Modular Design: Simplifies installation, servicing, and optional display or network module integration.
The VLP-002 delivers the reliability and precision required for early smoke detection in large, mission-critical spaces such as data centers, industrial facilities, and cleanrooms.
