VT5-W07M | Keyence 7" Monochrome TFT Touch Panel Display, IP65 Front, 24 VDC
- Regular price
- $1,529.00
- Sale price
- $1,529.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: VT5-W07M
Description
The Keyence VT5-W07M is a 7-inch widescreen monochrome TFT LCD touch panel designed as an operator interface for industrial automation systems. With durable construction, IP65-rated front protection, and long backlight life, it provides a reliable human-machine interface (HMI) for process monitoring and control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Keyence |
| Category | HMI / MMI / OIT |
| Part Number | VT5-W07M |
| Subcategory | Operator Interface |
| Display Type | TFT LCD Monochrome |
| Display Size | 7 inches (Widescreen) |
| Resolution | 800 × 480 (W × H dots) |
| Display Area | 153.6 × 86.6 mm (6.05" × 3.41") |
| Display Colors | 256 Grayscale |
| Touchscreen Type | Analog resistive |
| Touchscreen Lifespan | 1 million operations or more |
| Backlight Type | White LED (non-replaceable) |
| Backlight Life | Approx. 50,000 hours |
| Memory Capacity | 128 MB internal |
| Data Backup | Flash ROM + SRAM with lithium battery (5-year backup) |
| Power Supply Voltage | 24 VDC ±20% |
| Current Consumption | 900 mA or less |
| Vibration Resistance (Intermittent) | 5–9 Hz, 3.5 mm half amplitude; 9–150 Hz, 9.8 m/s² |
| Vibration Resistance (Continuous) | 5–9 Hz, 1.75 mm half amplitude; 9–150 Hz, 4.9 m/s² |
| Noise Resistance | 1500 Vp-p (1 µs, 50 ns pulse) |
| Withstand Voltage | 1500 VAC for 1 min between terminal and housing |
| Insulation Resistance | 50 MΩ or more (500 VDC megohmmeter) |
| Overvoltage Category | I |
| Pollution Degree | 2 |
| Operating Temperature Range | 0 to +50 °C (32 to 122 °F) |
| Storage Temperature Range | -20 to +60 °C (-4 to 140 °F) |
| Operating Humidity Range | 20 to 85% RH (no condensation) |
| Storage Humidity Range | 20 to 85% RH (no condensation) |
| Protection Rating | IP65 (front panel only, embedded type) |
| Construction Material | Panel-mount with sealed front face |
| Weight | Approx. 650 g (2.0 lb) |
Information About VT5-W07M
The VT5-W07M is part of Keyence’s VT5 Series, offering compact, high-performance HMI panels with advanced visualization and control features. It features an 800 × 480 resolution TFT LCD display supporting 256 grayscale levels and an analog resistive touchscreen for precise input. Equipped with onboard data storage, flash ROM, and a lithium battery backup, it ensures secure retention of display and operational data. The unit’s rugged design includes high vibration and noise resistance, making it ideal for factory automation, assembly systems, and equipment interfaces in harsh environments.
Key Features:
- 7-Inch Widescreen Display: 153.6 × 86.6 mm (6.05" × 3.41") active area for clear visual data representation.
- TFT LCD with 256 Grayscale: Provides sharp monochrome display suitable for industrial HMI use.
- High Durability Touchscreen: Analog resistive type rated for over 1 million operations.
- Long-Life Backlight: White LED backlight rated for approximately 50,000 hours.
- Data Backup Functionality: Stores screen and operational data using SRAM with lithium battery backup.
- Rugged Construction: Front panel rated IP65 with dust and water resistance for industrial environments.
- Strong Vibration Resistance: Withstands 5–150 Hz vibration per JIS B3502 and IEC 61131-2 standards.
- Noise and Overvoltage Protection: Rated for 1500 Vp-p and 1500 VAC isolation for stable operation.
- Wide Operating Range: Operates between 0 and +50 °C and up to 85% relative humidity.
- Compact and Lightweight: Easy installation into panel systems with reduced wiring requirements.
The VT5-W07M delivers the reliability and precision required for machine operation, production line control, and process visualization in industrial automation.
