Watlow 93BA-1CD0-00RG Series 93 Temperature Controller with Switched DC and Relay Outputs
- Regular price
- $989.00
- Sale price
- $989.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 93BA-1CD0-00RG
Description
The Watlow 93BA-1CD0-00RG is a microprocessor-based temperature/process controller for single-loop regulation in industrial equipment. It combines automatic tuning, a switched DC/open collector primary output, and an electromechanical relay secondary output in a compact 1/16 DIN panel-mounted enclosure.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Watlow |
| Category | Controls & Indicators |
| Part Number | 93BA-1CD0-00RG |
| Subcategory | Temperature/Process Control |
| Alternate Part Number | 93BA1CD000RG |
| Series | 93 |
| Controller Architecture | Microprocessor-based, single-input, dual-output |
| Mounting Format | 1/16 DIN panel mount |
| Input Compatibility | Type J, K, T, N, or S thermocouple; platinum RTD; 0–5 VDC or 4–20 mA process signal |
| Control Modes | PID or on/off |
| Tuning Function | Automatic tuning for heating and cooling |
| Output 1 | Switched DC/open collector, non-isolated |
| Output 2 | Electromechanical relay, Form C, 5 A resistive, without contact suppression |
| Supply Voltage / Frequency | 100–240 VAC nominal / 50–60 Hz |
| Display Configuration | Dual four-digit displays; red upper / green lower |
| Front-Panel Protection | IP65/NEMA 4X with correct panel installation |
| CE Option | Not included |
| Lifecycle / Listed Replacement | Discontinued by manufacturer / 2145-6845; verify application compatibility |
| Weight | 0.40 lbs |
Information About 93BA-1CD0-00RG
The 93BA-1CD0-00RG is a Series 93 controller configured with IP65/NEMA 4X front-panel protection and without the CE option. Its selectable input accommodates supported thermocouples, platinum RTDs, and analog process signals for integration with different measurement devices. The control functions include PID and on/off operation, with the secondary output configurable for opposing control action or alarm service. Separate red upper and green lower displays provide process and setpoint indication for local equipment operation.
Key Features:
- Automatic Tuning: Establishes PID parameters for the connected heating or cooling process.
- Selectable Control Modes: Supports PID and on/off regulation to match application requirements.
- Configurable Sensor Input: Accepts supported thermocouple, RTD, voltage, and current signals.
- Electronic Primary Output: Provides switched DC/open collector operation for a compatible external switching device.
- Mechanical Relay Output: Includes a 5 A Form C secondary relay for control or alarm functions.
- Front-Panel Protection: Provides IP65/NEMA 4X protection when installed according to manufacturer requirements.
- Dual-Color Displays: Uses a red upper display and green lower display for operating information.
- Parameter Retention: Stores configuration data in nonvolatile memory during power interruptions.
The 93BA-1CD0-00RG delivers the reliability and precision required for industrial heating, cooling, and process temperature regulation.
