Watlow DC21-60F0-0000 DIN-A-MITE Style C 3-Phase Solid-State Power Controller 600V 80A
- Regular price
- $939.00
- Sale price
- $939.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: DC21-60F0-0000
Description
The Watlow DC21-60F0-0000 is a high-performance DIN-A-MITE Style C solid-state power controller designed to regulate heavy electrical heating loads. Operating safely across a 277 to 600 VAC power spectrum, this three-phase unit utilizes advanced SCR switching technology to ensure stable and highly efficient thermal process management.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Watlow |
| Category | Industrial Automation |
| Part Number | DC21-60F0-0000 |
| Subcategory | Power Controllers |
| Module Series | DIN-A-MITE Style C |
| Power Phase | Three-Phase (2-Leg SCR) |
| Operating Voltage | 277 to 600 V AC |
| Input Signal | 4 to 20 mA DC |
| Maximum Current | 80 Amps |
| Mounting Style | DIN Rail / Panel Mount |
| Weight | 1.85 lbs |
Information About DC21-60F0-0000
The DC21-60F0-0000 is an industrial power control module built to handle massive electrical currents up to 80 amps smoothly. It utilizes a 4-20 mA DC input signal to modulate power output across a three-phase, two-leg configuration. Designed for compact footprint integration, this module easily mounts to standard DIN rails or flat back-panels inside crowded electrical cabinets. It features touch-safe terminals and rapid solid-state switching to eliminate mechanical arcing, greatly extending the operational life of connected resistive heating elements.
Key Features:
-
Solid-State Switching: Utilizes heavy-duty silicon controlled rectifiers to eliminate moving parts and prevent mechanical wear.
-
Three-Phase Power Management: Regulates high-voltage loads effortlessly across a dual-leg configuration.
-
High Amperage Capacity: Capable of securely switching heavy electrical loads up to 80 amps without overheating.
-
Touch-Safe Terminals: Protects maintenance technicians from accidental electrical contact during panel inspections.
-
Compact Footprint: Maximizes available cabinet space by offering both DIN-rail and direct panel mounting options.
-
4-20 mA Control Input: Integrates flawlessly with standard industrial analog signals for precise power modulation.
The DC21-60F0-0000 delivers the reliability and precision required for advanced heater control and intense industrial thermal regulation.
