Watlow PM6C1CJ-AAAAAAA EZ-ZONE PM Temperature Controller
- Regular price
- $525.00
- Sale price
- $525.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: PM6C1CJ-AAAAAAA
Description
Watlow PM6C1CJ-AAAAAAA is an EZ-ZONE PM temperature controller for regulating process heat in compact panel-mounted equipment. It has a universal input, switched DC/open-collector output, and a 5 A Form A mechanical relay output.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Watlow |
| Category | Temperature and Process Control |
| Part Number | PM6C1CJ-AAAAAAA |
| Subcategory | PID Temperature Controllers |
| Product family | EZ-ZONE PM |
| Controller type | Temperature/process controller |
| Input type | Universal |
| Control modes | PID, on/off |
| Output 1 | Switched DC/open collector |
| Output 2 | Mechanical relay, Form A, 5 A |
| Supply voltage | 100–240 VAC |
| Mounting format | 1/16 DIN panel mount |
| Communications | Watlow Standard Bus |
| Front interface | Smooth-touch keypad |
| Weight | 1.00 lb |
Information About PM6C1CJ-AAAAAAA
The PM6C1CJ-AAAAAAA is part of Watlow’s EZ-ZONE PM controller family in a 1/16 DIN panel-mount format. Its universal input works with compatible temperature or process sensors, while PID and on/off modes support different control requirements. Output 1 is switched DC/open collector and output 2 is a 5 A Form A mechanical relay. The configuration uses a 100–240 VAC supply and includes Watlow Standard Bus communications.
Key Features:
-
PID Temperature Control: Provides proportional-integral-derivative control for precise temperature and process regulation.
-
Universal Input: Accepts compatible thermocouples, RTD sensors, and analog process signals.
-
Switched DC Output: Includes an open-collector output rated up to 30 VDC and 100 mA for compatible control devices.
-
Mechanical Relay Output: Features a 5 A Form A relay output for switching compatible external loads.
-
Auto-Tuning Control: Supports automatic PID tuning with Watlow’s TRU-TUNE+ adaptive control algorithm.
-
Flexible Control Modes: Supports heat/cool, on/off, P, PI, PD, PID, and alarm control actions, depending on configuration.
-
Universal AC Power Supply: Operates on 100–240 VAC at 50/60 Hz.
-
Compact Panel Mounting: Uses a 1/16 DIN housing measuring approximately 48 × 48 mm.
-
Dual-Color Display: Features red and green display elements for monitoring process values and setpoints.
-
No Communications: This specific configuration is listed without digital communications options.
The PM6C1CJ-AAAAAAA delivers reliable temperature regulation for industrial heating, process control, and automation applications.
