WEB-600E-O | Honeywell Niagara AX Framework Controller
- Regular price
- $499.00
- Sale price
- $499.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: WEB-600E-O
Description
The WEB‑600E‑O is a compact embedded server/controller platform that integrates control, data logging, alarming, scheduling, and web serving into a small DIN-rail mountable chassis. It supports Internet connectivity for remote management and delivers real-time graphical views through standard web browsers.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Honeywell |
| Category |
Controls & Indicators
|
| Part Number | WEB-600E-O |
| Subcategory | Control Software |
| Platform | NiagaraAX (WEBs‑AX) on 524 MHz PowerPC, QNX RTOS |
| Ethernet Ports | 2 × 10/100 Mbps RJ‑45 |
| Serial Ports | 1 × RS‑232, 1 × RS‑485 |
| Protocols | LonWorks, BACnet, Modbus, oBIX, Niagara Network |
| I/O Expansion | Supports two internal comm cards and up to 34-point IO modules |
| Power Input | Universal 90–240 VAC, 50/60 Hz (plug-in power modules) |
| Data Backup | SRAM with battery-free recovery; optional NiMH battery adds ~10 min runtime |
| I/O Module Options | IO‑16-H (16 pts), IO‑34-H (34 pts + power) |
| Dimensions | ~318 × 105 × 82 mm (12.5×4.1×3.2 in) |
| Mounting | DIN-rail (NS35) or panel tabs |
| Environment | 0–50 °C operating; industrial reliability ratings |
| Weight | ~1.14 lb (0.52 kg) |
Information About WEB-600E-O
The WEB‑600E‑O is an open-licensed version of Honeywell’s discontinued WEB‑600E controller, running the NiagaraAX (WEBs‑AX) framework on a 524 MHz PowerPC with QNX OS. It includes two Ethernet ports, RS‑232/485, and supports optional communications and I/O expansion modules. Unique enhancements include battery-free data recovery services for SRAM-based backup, allowing continued operation during power disruptions; when equipped with an optional NiMH battery, it can sustain operation for up to 10 minutes. The controller supports industry protocols like LonWorks, BACnet, Modbus, and oBIX, making it ideal for distributed building and industrial automation systems with embedded web interfaces.
Key Features:
- NiagaraAX Framework: Embeds full WEBs‑AX control, alarming, scheduling, and HTML-based UI.
- Protocol Support: Native LonWorks, BACnet, Modbus, oBIX, Ethernet/IP, supporting interoperable networks.
- Redundant Data Retention: SRAM-backed memory with battery-free data recovery during outages.
- Optional NiMH Battery: Provides up to 10 minutes of buffer during major power loss.
- Dual Ethernet Ports: Enables network segregation and secure communication paths.
- Expandable: Supports two internal comms option cards and up to 34 local I/O modules via DIN rail modules.
- DIN Rail Mounted: Compact form (318 × 105 × 82 mm) for panel or DIN-rail installations.
- Rugged Build: Universal 90–240 VAC input; designed for industrial ambient environments.
- Real-Time Operation: Powered by a 524 MHz PowerPC under QNX RTOS for reliable deterministic performance.
- Web-based Interface: Standard browser UI for configuration, monitoring, and control without PC software.
- Open Licensing: The “‑O” version enables full access to NiagaraAX development, customization, and third-party integration.
The WEB‑600E‑O delivers comprehensive controller-server capabilities with reliable power and data integrity for façade automation, remote monitoring, and IoT systems.
