White Rodgers 50A50-405 Furnace Control Board HSI Single-Stage Gas Furnace Module
- Regular price
- $327.00
- Sale price
- $327.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 50A50-405
Description
The 50A50-405 is an integrated hot surface ignition (HSI) furnace control board designed for single-stage gas furnaces. It manages ignition sequencing, blower operation, and safety monitoring to ensure efficient and reliable furnace performance. This control board is compatible with various furnace models from brands like Lennox, Trane, and Rheem.
Technical Specifications
| Brand | White Rodgers |
| Category | HVAC Control Systems |
| Part Number | 50A50-405 |
| Subcategory | Furnace Control Boards |
| Control Type | Integrated Furnace Control Board |
| Ignition System | Hot Surface Ignition (HSI) |
| Heating Stages | Single-Stage |
| Operating Voltage | 24 VAC (Control), 120 VAC (Line) |
| Dimensions (L x W x H) | 7.5" x 5.8" x 1.6" |
| Weight | Approximately 1 lb (0.45 kg) |
| Diagnostic Indicators | LED Status Lights |
| Safety Features | System Fault Monitoring and Lockout |
| Compatible Brands | Lennox, Trane, Rheem, Robertshaw, Luxaire |
| Application | Residential Gas Furnaces |
Information About 50A50-405
The 50A50-405 is a microprocessor-based integrated furnace control board manufactured by White-Rodgers. It orchestrates the operation of the gas valve, ignitor, inducer draft motor, and circulating blower in single-stage heating systems. The board includes diagnostic LED indicators for troubleshooting and is designed to replace older models such as 50A50-406. Its compact design allows for straightforward installation in a variety of furnace units.
Key Features:
- Integrated Control: Manages gas valve, ignitor, inducer, and blower operations for single-stage furnaces.
- Hot Surface Ignition: Utilizes HSI technology for reliable and efficient burner ignition.
- Diagnostic LEDs: Provides visual indicators for system status and fault codes to aid in troubleshooting.
- Microprocessor-Based: Ensures precise control and monitoring of furnace operations.
- Safety Monitoring: Continuously checks for faults and initiates lockouts to prevent unsafe conditions.
- Compact Design: Measures approximately 7.5" x 5.8" x 1.6", facilitating easy installation.
- Wide Compatibility: Suitable for various furnace models from brands like Lennox, Trane, and Rheem.
- OEM Replacement: Serves as a direct replacement for models like 50A50-406.
- Voltage Rating: Operates on 24 VAC control voltage with 120 VAC line voltage.
- Durable Construction: Built with quality materials to withstand typical furnace operating conditions.
The 50A50-405 delivers the reliability and precision required for safe and efficient furnace operation in residential HVAC systems.
