WS-C2960XR-24TS-I | Cisco Gigabit Ethernet Switch
- Regular price
- $1,799.00
- Sale price
- $1,799.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: WS-C2960XR-24TS-I
Description
The Cisco WS-C2960XR-24TS-I is a 24-port Gigabit Ethernet Layer 2 switch with 4 SFP uplink ports, designed for enterprise-class access layer deployments.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
Radio Frequency Identification (RFID)
|
| Part Number | WS-C2960XR-24TS-I |
| Subcategory |
Radio Frequency Coaxial Switches
|
| Enclosure Type | Rack-mountable - 1U |
|
Ports
|
24 x 10/100/1000 + 4 x 1G SFP |
|
Network Management Interface
|
10/100 Mbps Ethernet (RJ-45) |
| Forwarding Bandwidth | 108Gbps |
| Maximum Stacking Number | 8 |
| Stack Bandwidth | 80G |
| Forwarding Performance | 71.4Mpps |
| Switching Bandwidth | 216Gbps |
| Maximum Active VLANs | 1023 |
| MAC Address Table Size | 16K (default) |
| RAM | 512 MB |
| Flash Memory | 128 MB |
| CPU | APM86392 600MHz dual core |
| Console Ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slot(s) | 1 FlexStack-Plus slot and 1 power redundant slot |
| Power Supply | PWR-C2-250WAC |
| Power Redundancy | Optional |
| Voltage Range (Auto) | 110V-240V |
| Power Consumption Operational | 0.038kVA |
| Operating Altitude | Up to 10,000 (Up to 3000 Meters) |
| Storage Altitude | Up to 13,000 (Up to 4000 Meters) |
| Operating Relative Humidity | 10% to 95% noncondensing |
| Storage Relative Humidity | 10% to 95% noncondensing |
| Weight | 5.9 kgs |
Information About WS-C2960XR-24TS-I
The Cisco WS-C2960XR-24TS-I is a Gigabit Ethernet Layer 2 switch built for enterprise access networks, offering robust performance, security, and scalability. It features 24 Gigabit Ethernet ports and 4 SFP uplinks, supporting high-throughput connectivity, energy efficiency, and optional Layer 3 routing capabilities, making it ideal for demanding business environments.
Key Features:
-
Product Type: Managed Gigabit Ethernet Switch
-
Port Configuration: 24 x 10/100/1000 Mbps ports + 4 x SFP uplink ports
-
Switching Capacity: Up to 216 Gbps
-
Forwarding Rate: Up to 107.1 Mpps
-
Layer Support: Layer 2 with basic Layer 3 (static routing, RIP)
-
Stacking Support: FlexStack-Plus (up to 8 units, 80 Gbps stack bandwidth)
-
Redundancy: Supports dual redundant power supplies for enhanced resiliency
-
Energy Efficiency: EnergyWise & Energy Efficient Ethernet (EEE) compliant
-
Security Features: 802.1X authentication, DHCP snooping, dynamic ARP inspection
-
Management Interface: Cisco IOS LAN Base, CLI and web-based tools
-
Dimensions: 44.5 x 36.8 x 4.45 cm (1 RU height)
-
User Type: Network administrators, IT infrastructure engineers, system integrators
-
Purpose: Reliable, secure, and scalable access layer connectivity in enterprise networks
-
Application Area: Campus LANs, branch offices, wired access for IP phones, PCs, and APs
-
Compliance: Meets enterprise networking and energy-efficiency standards
This switch is ideal for organizations seeking a cost-effective and flexible access layer solution that can scale with network demands. Its stacking and redundancy features help reduce downtime and simplify network management while supporting a smooth transition to Layer 3 services when needed.
