WS-C3560-8PC-S | Cisco Desktop Specialty Switch
- Regular price
- $369.00
- Sale price
- $369.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: WS-C3560-8PC-S
Description
The Cisco WS-C3560-8PC-S is a compact desktop switch featuring 8 Fast Ethernet PoE ports and 1 dual-purpose uplink (T/SFP), designed for small offices and branch deployments.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
Computer
|
| Part Number | WS-C3560-8PC-S |
| Subcatecory |
Networking Router
|
|
Switch Type
|
Catalyst switch 3560 Compact |
|
Port Count
|
8 |
|
Port Speed
|
10/100 Mbps |
|
PoE Support
|
Yes |
|
SFP Ports
|
1 T/SFP |
|
Image Type
|
IP Base Image |
|
Layer Support
|
Layer 3 |
|
Management
|
Managed |
|
VLANs Supported
|
255 |
|
Maximum VLANs
|
1005 |
|
MAC Address Table Size
|
8,000 entries |
|
Power Supply
|
Internal |
|
Input Voltage
|
100-240V AC |
|
Operating Temperature
|
0 to 40°C |
|
Humidity Range
|
10% to 85% non-condensing |
|
Dimensions (HxWxD)
|
4.4 cm x 26.9 cm x 17.6 cm |
|
Mounting Type
|
Desktop |
|
Weight
|
1.8 kgs |
Information About WS-C3560-8PC-S
The Cisco WS-C3560-8PC-S is a compact 8-port Fast Ethernet switch designed for small offices, branch locations, and retail deployments. It combines enterprise-class Layer 2 switching with Power over Ethernet (PoE) and limited Layer 3 static routing in a quiet, space-efficient form factor.
Key Features:
- Type: Desktop Specialty Switch (Catalyst 3560 Series)
- Ports Supported: 8 x 10/100 Mbps Fast Ethernet PoE ports; 1 x Dual-purpose uplink (10/100/1000 Ethernet or SFP)
- Switching Capacity: 8.8 Gbps switching fabric; 6.5 Mpps forwarding rate
- Forwarding Options: Layer 2 switching; Static Layer 3 routing (IP Base image)
- Installation Options: Desktop mounting; Wall-mount capable
- Supported Features: Power over Ethernet (up to 124W total PoE budget); VLAN support; Access Control Lists (ACLs); Quality of Service (QoS); 802.1X authentication; Basic static routing
- Power Consumption: Varies based on PoE load (up to 124W)
- Form Factor: Fanless, compact desktop unit
- Weight: Approximately 4.0 lb (1.8 kg)
The WS-C3560-8PC-S is ideal for environments that require silent operation, PoE support, and enterprise-grade security and reliability in a compact, easy-to-deploy form factor.
