Product Description P/N: WS-X6708-10G-3CXL
Description
The Cisco WS-X6708-10G-3CXL is a high-performance 10 Gigabit Ethernet module designed for the Cisco Catalyst 6500 and 7600 Series chassis. Supporting a wide range of IEEE standards, this module enables high-speed backbone and aggregation connectivity in large enterprise and service provider networks.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
Network Modules
|
| Part Number | WS-X6708-10G-3CXL |
| Subcategory | 10 Gigabit Ethernet Modules |
| Supported Protocols | IEEE 802.1d, 802.1p, 802.1q, 802.1s, 802.1w, 802.3x, 802.3ad, 802.3ae, 802.3ak, 802.3aq, 802.3an |
| Slot Requirement | 1 slot (Cisco Catalyst 6500/7600 Series) |
| Transceiver Compatibility | X2 modules (0.25 lbs each) |
| Power Requirement | 473.76 watts (11.28A 42V) |
| NEBS Compliance | SR-3580 Issue 3 (GR-63-CORE, GR-1089-CORE) |
| ETSI Standards | ETS 300 019-2-1 (Storage), ETS 300 019-2-2 (Transportation), ETS 300 019-2-3 (Stationary Use) |
| Dimensions (H x W x D) | 1.2 x 14.4 x 16 inches (3.0 x 35.6 x 40.6 cm) |
| Weight | 13 lbs (excluding X2 components) |
Information About WS-X6708-10G-3CXL
The WS-X6708-10G-3CXL offers eight 10 Gigabit Ethernet ports per slot, delivering high-density, high-bandwidth connectivity for demanding data center and core network environments. It supports a wide range of IEEE standards, including 802.1d, 802.1q VLAN tagging, 802.3ae 10G Ethernet, and 802.3an 10GBASE-T. The module is designed to fit a single slot in Cisco Catalyst 6500 or 7600 Series chassis, with dimensions of 1.2 x 14.4 x 16 inches (3.0 x 35.6 x 40.6 cm). It weighs approximately 13 pounds excluding X2 components, with each X2 transceiver weighing about 0.25 pounds.
Key Features:
- High-Density 10G Ports: Provides eight 10 Gigabit Ethernet ports per module, delivering exceptional throughput and connectivity for data center and core network environments.
- Broad Standards Support: Complies with key IEEE protocols, including 802.1d (Spanning Tree), 802.1q (VLAN tagging), 802.3ae (10G Ethernet), and 802.3an (10GBASE-T), ensuring broad compatibility with industry networking standards.
- Modular Design: Occupies a single slot in Cisco Catalyst 6500 or 7600 Series chassis, simplifying integration and expansion of existing network infrastructures.
- Physical Specifications: Compact design with dimensions of 1.2 x 14.4 x 16 inches and a weight of 13 pounds (excluding X2 components), facilitating easy installation and maintenance.
- Flexible Transceiver Options: Uses X2 pluggable transceivers for flexible deployment, allowing for easy adaptation to various fiber or copper connectivity requirements.
- High Power Efficiency: Requires approximately 473.76 watts, balancing high performance with manageable power consumption for demanding network environments.
- NEBS Compliance: Meets SR-3580 Issue 3 requirements for carrier-class reliability and performance, ensuring suitability for service provider and telecom deployments.
The WS-X6708-10G-3CXL delivers high-density, high-performance 10G Ethernet connectivity, making it an essential component for modern, scalable network architectures.
