Xtralis VPS-100US-220 24VDC Fire Alarm Power Supply 220 VAC
- Regular price
- $805.00
- Sale price
- $805.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: VPS-100US-220
Description
The Xtralis VPS-100US-220 is a 220 VAC power supply designed to provide regulated 24 VDC operating power and battery backup for Xtralis VESDA aspirating smoke detection systems. It supports a single detector or multiple remote devices while continuously supervising AC power, battery status, and output conditions to ensure uninterrupted operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Xtralis |
| Category | Fire Alarm Systems |
| Part Number | VPS-100US-220 |
| Subcategory | Fire Alarm Power Supplies |
| Product Type | 24 VDC Regulated Power Supply |
| Input Voltage | 220 VAC, 60 Hz |
| Output Voltage | 24 VDC Nominal (19.96–27.54 VDC) |
| Continuous Output Current | 1.5 A Maximum |
| Maximum Output per Circuit | 1.2 A |
| Battery Requirement | Two 12 VDC, 12 Ah Sealed Lead Acid Batteries |
| Battery Charging | Integrated Automatic Charger |
| Supported Devices | Up to 5 Remote Units, 1 Remote Subrack, 2 LaserCOMPACT Units, or 1 LaserPLUS/LaserFOCUS/LaserSCANNER |
| Trouble Monitoring | AC Failure, Brown-Out, Battery Supervision |
| Relay Outputs | Local and Remote Form C Trouble Relays |
| Operating Temperature | 0°C to 49°C (32°F to 120°F) |
| Humidity | 10–95% RH, Non-Condensing |
| Dimensions (W × H × D) | 13.9 × 9.0 × 4.5 in. (353 × 229 × 114 mm) |
| Weight | 7.5 lb (3.4 kg), Without Batteries |
Information About VPS-100US-220
The VPS-100US-220 is part of the Xtralis VESDA Power Supply Series developed specifically for VESDA aspirating smoke detection equipment and compatible accessories. Operating from a 220 VAC input, it delivers a regulated 24 VDC output with integrated battery charging and automatic transfer to standby batteries during AC power loss. The unit is capable of powering up to five remote single-box units, one remote 19-inch subrack, two LaserCOMPACT units, or one LaserPLUS, LaserFOCUS, or LaserSCANNER detector. Built with supervised outputs, fault relays, and battery monitoring, it provides dependable power management for critical fire detection systems.
Key Features:
- 220 VAC Input: Designed for 220 VAC, 60 Hz power systems.
- Regulated 24 VDC Output: Supplies stable operating power for VESDA detection equipment.
- Battery Backup Support: Charges and supervises two 12 VDC, 12 Ah standby batteries.
- Multiple Device Support: Powers up to five remote units or selected VESDA detector configurations.
- Automatic Battery Switchover: Maintains system operation during AC power failures.
- Built-In Supervision: Monitors AC input, battery condition, and power supply faults.
- Continuous Output Current: Delivers up to 1.5 A of regulated output current.
- Fire Alarm Certified Design: Intended for UL-listed fire protective signaling applications.
The VPS-100US-220 delivers the reliability and regulated power required for continuous operation of VESDA aspirating smoke detection systems.
