Yaskawa CIMR-AU4A0004FAA A1000 Series AC Variable Frequency Drive
- Regular price
- $999.00
- Sale price
- $999.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CIMR-AU4A0004FAA
Description
Yaskawa CIMR-AU4A0004FAA is an A1000 series AC drive designed for three-phase motor control in industrial applications. It operates from a 380–480 VAC supply and provides 1 HP constant-torque or 2 HP variable-torque motor capacity, with NEMA 1 enclosure protection.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Yaskawa |
| Category | Drives |
| Part Number | CIMR-AU4A0004FAA |
| Subcategory | AC Drives |
| Product Series | A1000 |
| Phase | 3-phase |
| Input Voltage | 380–480 VAC |
| Constant Torque Rating | 1 HP |
| Variable Torque Rating | 2 HP |
| Constant Torque Current | 3.4 A |
| Variable Torque Current | 4.1 A |
| Control Method | Open/closed-loop vector control |
| Braking | DC injection; dynamic braking transistor included |
| Keypad | Included |
| Enclosure Rating | NEMA 1 |
| Protection Rating | IP20 |
| Dimensions | 11.81 × 5.51 × 5.79 in |
| Weight | 7.00 lb |
Information About CIMR-AU4A0004FAA
The CIMR-AU4A0004FAA belongs to Yaskawa’s A1000 family of all-purpose AC drives and supports open- and closed-loop vector control. The drive is rated at 3.4 A for constant-torque applications and 4.1 A for variable-torque applications. It includes a keypad, dynamic braking transistor, DC injection braking, and optional closed-loop operation. The A1000 platform also supports motor auto-tuning, communication options, and programmable functions for integration into industrial control systems.
Key Features:
- A1000 Series: Part of Yaskawa’s A1000 family of all-purpose AC drives.
- Three-Phase Operation: Designed for 380–480 VAC three-phase power systems.
- Motor Capacity: Supports 1 HP constant-torque and 2 HP variable-torque applications.
- Vector Control: Provides open- and closed-loop vector control for motor regulation and torque control.
- Dynamic Braking: Includes an integrated dynamic braking transistor for controlled motor deceleration.
- Keypad Included: Provides local operator controls for drive configuration and operation.
- NEMA 1 Enclosure: Designed with a NEMA Type 1 enclosure for indoor industrial installations.
- Auto-Tuning: Supports continuous auto-tuning to compensate for motor temperature changes.
The CIMR-AU4A0004FAA provides flexible motor control and braking functions for a wide range of industrial AC drive applications.
