ZV2-N22-2S | Omron Enclosed Switch
- Regular price
- $215.00
- Sale price
- $215.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: ZV2-N22-2S
Description
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| BrandPart Number | Omron |
| Category |
Servo Products
|
| Part Number | ZV2-N22-2S |
| Subcategory | Servo Motor |
| Series | ZV2 |
| Type | General Purpose, High Breaking Capacity |
| Contact Form | SPDT (Single Pole Double Throw) |
| Switch Function | ON-(OFF), OFF-(ON) |
| Actuator Type | Sealed Roller Plunger |
| Actuator Style | Roller Plunger |
| Current Rating | 15 A |
| Voltage Rating (AC) | 125 VAC |
| Voltage Rating (DC) | 125 VDC |
| Operating Force | 500 gf |
| Termination Style | Screw |
| Mounting Style | Chassis Mount (Diagonal Side Mounting) |
| Conduit Entry | 1/2 - 14 NPSM without ground terminal |
| IP Rating | IP65 |
| Illuminated | Non-Illuminated |
| Minimum Operating Temperature | -10 °C |
| Maximum Operating Temperature | +80 °C |
| High Durability | Yes (High Mechanical & Electrical Durability) |
| Weight | 0.27 kgs |
Information About ZV2-N22-2S
The Omron ZV2-N22-2S is a heavy-duty enclosed limit switch designed for reliable position sensing in industrial environments. Part of the ZV2 Series, this switch features a sealed roller plunger actuator and a single-pole double-throw (SPDT) contact configuration. With an IP65-rated die-cast aluminum housing, it offers high durability and resistance to dust and water ingress. Its high breaking capacity and long mechanical life make it ideal for applications requiring robust switching performance in harsh conditions.
Key Features:
- Sealed Roller Plunger Actuator: Ensures accurate actuation in dusty or humid environments.
- SPDT Contact Form: Provides flexible switching for control circuit applications.
- High Current Rating (15 A): Handles significant load switching up to 125 VAC or 125 VDC.
- High Breaking Capacity: Suitable for heavy-duty applications with resistive and inductive loads.
- IP65 Protection: Dust-tight and protected against low-pressure water jets for outdoor and industrial use.
- Die-Cast Aluminum Housing: Offers structural strength and resistance to mechanical wear.
- Diagonal Side Mounting with G1/2 Conduit Entry: Supports easy installation in standard industrial setups.
- Wide Operating Temperature Range: Operates reliably from –10°C to +80°C.
- Screw Terminal Connections: Simplifies field wiring during installation and maintenance.
- Non-Illuminated Design: Simplifies construction while providing reliable mechanical feedback.
- Discontinued Model: Available primarily through surplus and aftermarket channels for legacy equipment.
The Omron ZV2-N22-2S delivers rugged, high-capacity switching for demanding factory environments. Its sealed plunger actuator, robust housing, and IP65 protection make it suitable for conveyors, machine tools, and outdoor industrial equipment where mechanical durability and environmental resistance are critical.
